Install and Upgrade Internal Modules and Field
Replaceable Units
The Cisco 1000 Series Integrated Services Routers have internal modules and field-replaceable units (FRUs)
that can be quickly and easily removed and replaced without having to send the entire router for repair.
This section describes how to install the internal modules and FRUs in the Cisco 1000 Series Integrated
Services Routers. The information is contained in the following sections:
•
•
•
•
•
Replace the Chassis Covers for C111X and C1111x
To access the internal modules on the router, you must first remove the chassis cover. See the instructions
below on how to remove and later replace the chassis cover on the routers.
Warning
Cisco 1000 Series Integrated Services Routers have removable covers. Do not run the routers with the cover
off. Doing so can cause the router to overheat very quickly.
Use a number-2 Phillips screw driver to perform the following tasks.
Replace the Chassis Covers for C111X and C1111x, on page 1
External Modules, on page 4
Install and Remove Small Form Pluggable Modules, on page 5
Install a Pluggable Interface Module, on page 6
Installing a SIM Card on C111X, C1109-2PX, C1109-4P, on page 26
Only trained and qualified personnel should be allowed to install, replace or service this equipment. Statement
1030
Install and Upgrade Internal Modules and Field Replaceable Units
1
Advertisement
Table of Contents
Related Manuals for Cisco C1109-2PX
Summary of Contents for Cisco C1109-2PX
- Page 1 This section describes how to install the internal modules and FRUs in the Cisco 1000 Series Integrated Services Routers. The information is contained in the following sections: •...
-
Page 2: Remove The Cover
Install and Upgrade Internal Modules and Field Replaceable Units Remove the Cover Remove the Cover To remove the cover, do these steps: 1 and 2 Remove the 14 screws from either side of the cover. Step 1 Read the Safety Warnings and disconnect the power supply before you perform any module replacement. Step 2 Confirm the router is turned off and disconnected from the power supply. -
Page 3: Replace The Cover
Install and Upgrade Internal Modules and Field Replaceable Units Replace the Cover Step 3 Disconnect all port cables connected to the router. Ensure that you do not work on the router with cables still attached to the router in the event of lightning or surges. Step 4 Place the chassis on a flat surface. -
Page 4: External Modules
Install the fourteen screws on both sides of the chassis. Torque to 6-8 in-lbs. External Modules This section describes how to install external modules and FRUs in the Cisco 1000 Series Integrated Services Routers. The information is contained in the following sections: Warning Only trained and qualified personnel should be allowed to install, replace or service this equipment. - Page 5 Install and Remove Small Form Pluggable Modules Install and Remove Small Form Pluggable Modules This section describes how to install and remove Small Form Pluggable (SFP) modules in the Cisco 1000 Series Integrated Services Routers. The information is contained in the following sections:...
- Page 6 Install and Upgrade Internal Modules and Field Replaceable Units Install a Pluggable Interface Module Install a Pluggable Interface Module Warning Blank faceplates and cover panels serve three important functions: they prevent exposure to hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI) that might disrupt other equipment;...
- Page 7 Install and Upgrade Internal Modules and Field Replaceable Units Install a Pluggable Interface Module on a C1101-4P Ground lug Kensingston lock slot Figure 2: LTE Pluggable Interface Module - C1127X-8PLTEP GPS antenna (SMA) LTE antenna (SMA) Ground lug Kensingston lock slot Install and Upgrade Internal Modules and Field Replaceable Units...
- Page 8 Install and Upgrade Internal Modules and Field Replaceable Units Install a Pluggable Interface Module on a C1101-4P Figure 3: LTE Pluggable Interface Module - P-LTEAP18-GL Main 0 antenna (SMA) Diversity 1 antenna (SMA) Micro USB Diversity 0 antenna (SMA) Main 1 antenna (SMA) Enable LED SIM 0 LED SIM 1 LED...
- Page 9 Install and Upgrade Internal Modules and Field Replaceable Units Install a Pluggable Interface Module on a C1101-4P Figure 4: 5G Pluggable Interface Module - P-5GS6-GL antenna 1 (SMA) GPS (SMA) Antenna 3 (SMA, reception only) Antenna 0 (SMA) Antenna 2 (SMA) Enable LED SIM 0 LED SIM 1 LED...
- Page 10 Install and Upgrade Internal Modules and Field Replaceable Units Install a Pluggable Interface Module on a C1101-4P Figure 5: PLTEA-LA with Micro SIM Slots Main antenna (SMA) GPS (SMA) Diversity antenna (SMA) Enable LED SIM 0 LED SIM 1 LED GPS LED M3.5 thumb-screw Micro USB 2.0...
- Page 11 Install and Upgrade Internal Modules and Field Replaceable Units Install a Pluggable Interface Module on a C1101-4P Note Ensure to use the correct tool for removing the Micro-SIM door. 1. Place the pluggable module on its bottom side, remove the SIM door screw, use a #1 Philips screw driver for removing the screws, and then carefully remove the Micro-SIM cover from the pluggable module.
- Page 12 Install and Upgrade Internal Modules and Field Replaceable Units Configuring a Pluggable Interface Module Figure 6: Insert the Micro-SIM Cards Configuring a Pluggable Interface Module To insert the antenna in the Pluggable Interface Module, perform the following steps: Install and Upgrade Internal Modules and Field Replaceable Units...
- Page 13 Install and Upgrade Internal Modules and Field Replaceable Units Configuring a Pluggable Interface Module Figure 7: Attaching the Antennas Step 1 Use your thumb and index finger to insert and tighten antenna 1 and antenna 3 in the middle antenna attachment slots, as indicated in the figure.
- Page 14 Install and Upgrade Internal Modules and Field Replaceable Units RF Band Mapping for Antenna Ports (For P-5GS6-GL only) RF Band Mapping for Antenna Ports (For P-5GS6-GL only) The following table lists the RF band mapping for antenna ports. RF Band Mapping for Antenna Ports: Antenna Technology Port...
-
Page 15: Led Behaviors
Install and Upgrade Internal Modules and Field Replaceable Units LED Behaviors Antenna Technology Port ANT 1 B1, B2, B3, B4, B5, B6, B8, B9, B19 WDCMA B5, B20, B42, B43, B48, B71 B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71... -
Page 16: Attaching The Antennas
Install and Upgrade Internal Modules and Field Replaceable Units Attaching the Antennas Color Function • Off: SIM0 is not installed • Yellow: SIM0 is installed, but not active • Green: SIM0 installed and active • Green Blink: LTE data activity SIM1 Green, Yellow SIM1 LED/Activity... - Page 17 Install and Upgrade Internal Modules and Field Replaceable Units Attaching the Antennas Figure 8: Attaching the 5G New Radio (NR) Antenna (5G-ANTM-O4-B) to P-5GS6-GL PIM Note 5G NR Antenna (5G-ANTM-04-B) is supported on both P-LTEAP18-GL and P-5GS6-GL PIMs. 1. Attach each SMA cable to the ports as indicated in the table mappings. 2.
- Page 18 GNSS connection The following link contains the antenna specifications and installation instructions for 5G NR (5G-ANTM-O-4-B): https://www.cisco.com/c/en/us/td/docs/routers/connectedgrid/antennas/installing-combined/ b-cisco-industrial-routers-and-industrial-wireless-access-points-antenna-guide/m-5g-antm-04b.html#Cisco_ Generic_Topic.dita_e780a6fe-fa46-4a00-bd9d-1c6a98b7bcb9 Install a Micro-SIM Card into a USB LTE Dongle This section describes how to insert a micro-SIM card into a USB LTE dongle in a C1101-4P router.
- Page 19 Install and Upgrade Internal Modules and Field Replaceable Units Install a Micro-SIM Card into a USB LTE Dongle Step 2 To remove a micro-SIM card into a USB LTE dongle, do these steps: a. Tap open the dust cover, and then gently push the micro-SIM card to eject the card from the SIM slot. b.
-
Page 20: Antenna Mounting Instructions
Follow the same procedure to install the USB LTE dongle onto routers with a vertical USB slot. Antenna Mounting Instructions This section describes how to mount the antenna on the Cisco 1000 Series Integrated Services Router. The information is contained in the following sections:... - Page 21 Install and Upgrade Internal Modules and Field Replaceable Units Option A - Rack Mount at the Same Height with the Platform Option A - Rack Mount at the Same Height with the Platform Step 1 Pick up the R-Brackets (700-121611-01)Place and fix the bracket at an appropriate location on the rack using two screws. Step 2 Tighten the screw, the recommended torque is 10-12 in-lb.
- Page 22 Install and Upgrade Internal Modules and Field Replaceable Units Wall Mount of the Antenna Wall Mount of the Antenna To install the antenna on a wall, do these steps: Install and Upgrade Internal Modules and Field Replaceable Units...
- Page 23 Install and Upgrade Internal Modules and Field Replaceable Units Step 1 Pick up the C-Bracket (700-121628-01), place the bracket and then fix it on the wall using four screws. Step 2 Assemble the USB cable (74-122795-01), dongle and antenna (07-100470-01) together. Pick up the wall-mount bracket (700-121609-01), two SCREWS (48-0580-01).
- Page 24 Install and Upgrade Internal Modules and Field Replaceable Units Ceiling Mount of the Antenna Ceiling Mount of the Antenna To install the antenna on a rack, do these steps: Option A - Rack Mount at a Different Height with the Platform Step 1 Pick up the R-Brackets (700-121611-01) Step 2...
- Page 25 Install and Upgrade Internal Modules and Field Replaceable Units Option A - Rack Mount at the Same Height with the Platform Option A - Rack Mount at the Same Height with the Platform Step 1 Pick up the R-Brackets (700-121611-01)Place and fix the bracket at an appropriate location on the rack using two screws. Step 2 Tighten the screw, the recommended torque is 10-12 in-lb.
- Page 26 Install and Upgrade Internal Modules and Field Replaceable Units Installing a SIM Card on C111X, C1109-2PX, C1109-4P Installing a SIM Card on C111X, C1109-2PX, C1109-4P The SIM card socket is located on the I/O side of the unit. Install and Upgrade Internal Modules and Field Replaceable Units...
- Page 27 Install and Upgrade Internal Modules and Field Replaceable Units Installing a SIM Card on C111X, C1109-2PX, C1109-4P Figure 11: Removing SIM Cover and Inserting SIMs into C111X SIM Cover SIM 0 SIM 1 The unit supports dual SIM cards behind a SIM cover. To insert the SIM cards, perform the following steps:...
- Page 28 Install and Upgrade Internal Modules and Field Replaceable Units Installing a SIM Card on C111X, C1109-2PX, C1109-4P Figure 12: SIMs Inserted Micro SIM slots SIM 0 slot SIM 1 slot Orientation notch (SIM 0) Orientation notch (SIM 1) 1. Use a flat screw driver to pry and remove the SIM cover.
