H3C LSQM1WCMB0 Installation Manual
Access controller module
Hide thumbs
Also See for LSQM1WCMB0:
- Quick start manual (10 pages) ,
- Configuration manual (64 pages) ,
- Installation manual (50 pages)
Related Manuals for H3C LSQM1WCMB0
Summary of Contents for H3C LSQM1WCMB0
- Page 1 H3C LSQM1WCMB0 Access Controller Module Installation Guide Abstract This document details the installation procedures for the LSQM1WCMB0 access controller module. Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com...
- Page 2 However, the statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. Hangzhou H3C Technologies Co., Ltd. and its licensors shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Contents 1 Product Overview ·············································································································· 5 Introduction ································································································································· 5 Physical properties of the LSQM1WCMB0 ······················································································· 5 Technical specifications ··········································································································· 5 Front panel and LEDs ··············································································································· 6 2 Installation preparations ······································································································ 8 Safety Precautions························································································································ 8 General Safety Recommendations ··························································································· 8 Electricity Safety ······················································································································ 8 ESD Prevention ························································································································... - Page 4 Starting up the LSQM1WCMB0 ····································································································· 21 Checks before power-on ······································································································· 21 Powering on the access controller module ·············································································· 22 5 Troubleshooting ················································································································24 Troubleshooting the configuration system····················································································· 24 6 Support and other resources ······························································································25 Related documentation ············································································································· 25 Contacting H3C ························································································································· 25 Technical support ··················································································································...
-
Page 5: Product Overview
The LSQM1WCMB0 is an access controller module for the H3C S7502E/S7503E/S7506E/S7506E-V/ S7510E Ethernet switches. NOTE: The models listed in this manual are not applicable to all regions. Please consult H3C representatives for the models applicable to your region. Introduction The LSQM1WCMB0 access controller module provides wireless access control functionality. -
Page 6: Front Panel And Leds
0°C to 45°C (32°F to 113°F) Relative humidity (noncondensing) 10% to 90% Front panel and LEDs For a description of the front panel of the LSQM1WCMB0, see Figure 2 . Figure 2 Front panel of the LSQM1WCMB0 (2) (3) (1) USB interfaces... - Page 7 Table 2 Description of the management Ethernet interface LEDs LEDs Meaning Off: No link is present. LINK On: A link is present. Off: No data is being transmitted/received. Blinking: Data is being transmitted/received.
-
Page 8: Installation Preparations
NOTE: Clean the air filter on the switch chassis during the use of the LSQM1WCMB0 to prevent poor ventilation. Electricity Safety ... -
Page 9: Esd Prevention
Locate the emergency power switch in the equipment room before installing the access controller module so that you can cut off the power immediately in case of accident. Avoid maintaining the access controller module alone with the switch powered on. ... -
Page 10: Installation Site Examination
The accessories vary with the models. For the exact contents of the package, refer to the packing list. If the contents do not match the packing list, contact your H3C representative. If the package is found to be rusted or water soaked, stop unpacking and contact your H3C representative immediately. -
Page 11: Emi Prevention
ESD prevention to ensure the stable and reliable operation of the switch and the access controller module. Installation tools and meters When installing the access controller module, you may need the tools listed in Table 5 These installation tools and meters are not shipped with the LSQM1WCMB0. - Page 12 Table 5 List of installation tools and meters Type Tools Fastening tools Phillips screwdrivers Special tools ESD-preventive wrist strap Fiber cleaning tools Airlaid paper, fiberscope Multimeter, 500V Megohmmeter (for Meters measuring insulation resistance), earth resistance tester...
-
Page 13: Hardware Installation
The console cable is an 8-core cable with an RJ-45 connector at one end for the console port of the LSQM1WCMB0 and a DB-9 female connector at the other end for the 9-pin serial port of a configuration terminal (see Figure 3... -
Page 14: Connecting The Console Cable
When the LSQM1WCMB0 is powered on, H3C recommends using the following order when connecting or disconnecting the console cable: When connecting the LSQM1WCMB0 to a PC, first connect the DB-9 connector of the console cable to the PC and then connect the RJ-45 connector to the LSQM1WCMB0. ... -
Page 15: Removing And Installing The Lsqm1Wcmb0
Removing and installing the LSQM1WCMB0 This section describes how to remove and install the LSQM1WCMB0 module. NOTE: This module is hot swappable. Removing the LSQM1WCMB0 Figure 4 Remove the LSQM1WCMB0 Face the front side of the switch. Using a Philips screwdriver, loosen the captive screws on the access controller module. -
Page 16: Installing The Lsqm1Wcmb0 Module
Installing the LSQM1WCMB0 module Face the front side of the switch. Choose an empty slot and remove the blank filler panel. Push the access controller module into slot along the guide rails until the positioning hole of the board is seated onto the positioning pin on the backplane. -
Page 17: Initial Startup Of The Access Controller Module
Setting up a configuration environment Set up a configuration environment by connecting the console port of the LSQM1WCMB0 access controller module to a console terminal, a PC in this example (see Figure 5 Figure 5 Set up a network connection for LSQM1WCMB0 configuration... - Page 18 HyperTerminal. The Connection Description dialog box appears (see Figure 6 Figure 6 Set up a new connection Type a name, H3C in this example, for the new connection in the Name field and click OK. The Connect To dialog box appears (see Figure 7...
- Page 19 Figure 7 Connect To dialog box Using the Connect using drop-down list, select the serial port to which the console cable is actually connected. Click OK. Set serial port parameters (see Figure 8 To use the default settings, click Restore Defaults.
- Page 20 Figure 8 Set serial port parameters Click OK. The HyperTerminal window appears (see Figure 9 Figure 9 HyperTerminal window Set HyperTerminal properties. In the HyperTerminal window, choose File > Properties from the menu, and select the Settings tab to enter the properties setting dialog...
-
Page 21: Starting Up The Lsqm1Wcmb0
(see Figure 10 ). Select VT100 or Auto detect from the Emulation drop-down list, and click OK to return to the HyperTerminal window. Figure 10 Set the emulation type Starting up the LSQM1WCMB0 Checks before power-on Before starting up the access controller module, verify that: ... -
Page 22: Powering On The Access Controller Module
To enter the BootWare main menu, press Ctrl + B within five seconds. For details about the BootWare main menu, refer to BootWare Main Menu in the H3C LSQM1WCMB0 Software Maintenance Guide. If you perform no operation or press a key other than Ctrl + B within five seconds, once the remaining comes to 0, the system starts the auto boot process. - Page 23 The LSQM1WCMB0 access controller module provides many command views. For detailed descriptions about the configuration commands and the CLI, refer to H3C WX Series Access Controllers Command References. To learn more about access controller software maintenance, see H3C LSQM1WCMB0...
-
Page 24: Troubleshooting
Troubleshooting Troubleshooting the configuration system If the LSQM1WCMB0 access controller module passes the power-on self test (POST) after the switch is powered on, the console terminal that is connected with the access controller module displays the startup banner and prompt messages. If the configuration system is faulty, you may see nothing or illegible characters on the console terminal. -
Page 25: Support And Other Resources
Web-Based Configuration Guide the WX series access controllers. Contacting H3C Technical support For worldwide technical support information, see the H3C support website: http://www.h3cnetworks.com Related information Register your product Warranty and other service benefits start from the date of purchase, so it is important to register your product quickly to ensure you get full use of the warranty and other service benefits available to you. - Page 26 Support tools are posted on the web site at http://www.h3cnetworks.com/ under Support, Knowledgebase. The Knowledgebase helps you troubleshoot H3C products. This query-based interactive tool contains thousands of technical solutions. Access software downloads Software Updates are the bug fix / maintenance releases for the version of software initially purchased with the product.
-
Page 27: Document Conventions And Symbols
Find a current directory of contact information posted on the web site at http://www.h3cnetworks.com/ under Support, Technical Support Contact. Documentation feedback You can e-mail your comments about product documentation to info@h3c.com. We appreciate your comments. Environmental Protection This product has been designed to comply with the requirements on environmental protection. -
Page 28: Symbols
• Bold text Keys that are pressed • Text entered into a GUI element, such as a box • GUI elements that are clicked or selected, such as menu and list items, buttons, tabs, and check boxes Italic text Text emphasis •... - Page 29 TIP: Provides helpful hints and shortcuts.
