www.ti.com
4 Getting Familiar with the controlCARD
4.1 F2800137 controlCARD Features
•
F2800137 Microcontroller – High performance C2000 microcontroller is located on the controlCARD.
•
120-pin HSEC8 Edge Card Interface – Allows for compatibility with all of C2000 180-pin controlCARD-
based application kits and controlCARDs. Compatibility with 100-pin controlCARDs can be accomplished
using the TMDSADAP180TO100 adapter card (sold separately).
•
Built-in Isolated JTAG Emulation – An XDS110 emulator provides a convenient interface to Code
Composer Studio
™
IDE without additional hardware. Flipping a switch allows an external JTAG emulator
to be used.
•
Built-in Isolated Power Supply - Passes the 5 V supply from the USB-C connector through an isolation
barrier. Allows for the controlCARD to be completed powered and operated from the USB-C connector. The
F2800137 is fully isolated from the USB port.
•
Automatic Power Supply Switch - The controlCARD automatically switches to external 5 V power when
present. No additional configuration is required.
•
Connectivity – The controlCARD contains connectors that allow the user to experiment with isolated
universal asynchronous receiver/transmitter (UART)/SCI with the F280013x MCU.
•
Key Signal Breakout – Most GPIO, analog-to-digital converter (ADC) and other key signals routed to hard
gold connector fingers.
•
Robust Power Supply Filtering – Single 5 V input supply powers an on-card 3.3 V LDO. All MCU inputs are
then decoupled using LC filters near the device.
•
ADC Clamping – ADC inputs are clamped by protection diodes.
•
Anti-Aliasing Filters – Noise filters (small RC filters) can be easily added on ADC input pins.
4.2 Assumed Operating Conditions
This kit is assumed to run at standard room conditions. Standard ambient temperature and pressure (SATP) with
moderate-to-low humidity is assumed.
4.3 Power Supply Requirements
For the controlCARD to operate, the controlCARD MCU must be powered. This can be done through the USB-
connector on the controlCARD or by inputting 5 V through the HSEC connector by way of an accompanying
baseboard. For example if using a TMDSHSECDOCK docking station baseboard, 5-V DC can be input into the
docking station J1 or J17. Then, S1 on the docking station needs to be toggled to the appropriate position.
4.3.1 External Power Supply or Accessory Requirements
Nominal Output Voltage: 5 VDC
Maximum Output Current: 3 A
Efficiency Level V
TI recommends using an external power supply or power accessory that complies with applicable
regional safety standards such as (by example) UL, CSA, VDE, CCC, PSE, and so on.
4.4 Using the controlCARD
Based on the way the controlCARD is used, additional hardware settings can be necessary (see
When the controlCARD is used in a high-voltage setup, it is the user's responsibility to confirm that
the voltages and isolation requirements are identified and understood prior to energizing the board
or simulation. When energized, the controlCARD or components connected to the controlCARD
can not be touched. Furthermore, the capacitor C7:A can be removed to minimize the possibility of
leakage current flowing across the isolation barrier of the controlCARD.
SPRUJ15B – NOVEMBER 2021 – REVISED OCTOBER 2022
Submit Document Feedback
Note
WARNING
Copyright © 2022 Texas Instruments Incorporated
Getting Familiar with the controlCARD
TMDSCNCD2800137 controlCARD Information Guide
Table
4-1).
5
