Carrier FAS150 Installation, Start-Up And Service Instructions Manual

Packaged air-handling units with r-410a refrigerant 60 hz
Hide thumbs Also See for FAS150:
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . 1
PRE-INSTALLATION . . . . . . . . . . . . . . . . . . . . . . 2
Moving and Storage . . . . . . . . . . . . . . . . . . . . . . 2
Rigging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Uncrating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rated Indoor Airflow (cfm) . . . . . . . . . . . . . . . . 10
Unit Positioning . . . . . . . . . . . . . . . . . . . . . . . . 10
Unit Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Refrigerant Piping . . . . . . . . . . . . . . . . . . . . . . . 11
Refrigerant Piping Access . . . . . . . . . . . . . . . . 11
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . 14
Fan Motors and Drives . . . . . . . . . . . . . . . . . . . . 15
Power Supply and Wiring . . . . . . . . . . . . . . . . . . 15
Variable Frequency Drive . . . . . . . . . . . . . . . . . 18
Connecting Ductwork . . . . . . . . . . . . . . . . . . . . 20
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . 21
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
FAS/FHS ONLY . . . . . . . . . . . . . . . . . . . . . . . . . 22
Compressor Rotation . . . . . . . . . . . . . . . . . . . . 22
Indoor Fan Motor . . . . . . . . . . . . . . . . . . . . . . . 22
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan Speed Set Up . . . . . . . . . . . . . . . . . . . . . . . 23
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . 24
(and 30 days after initial start) . . . . . . . . . . . 24
Seasonal Maintenance . . . . . . . . . . . . . . . . . . . 24
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Fan Motor Lubrication . . . . . . . . . . . . . . . . . . . 25
Fan Shaft Bearings . . . . . . . . . . . . . . . . . . . . . . 25
Centering Fan Wheel . . . . . . . . . . . . . . . . . . . . 25
FAS/FHS150-180
Packaged Air-Handling Units
with R-410A Refrigerant
Installation, Start-up and
Service Instructions
Page
FASFHS150-180-01SI
60 Hz
Fan Shaft Position Adjustment . . . . . . . . . . . . 25
Individual Fan Wheel Adjustment . . . . . . . . . . 25
Fan Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Fan Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Fan Pulley Alignment . . . . . . . . . . . . . . . . . . . . 26
Pulley and Drive Adjustment . . . . . . . . . . . . . . 27
Variable Frequency Drive . . . . . . . . . . . . . . . . 32
Bypass the VFD . . . . . . . . . . . . . . . . . . . . . . . . 36
Condensate Drains . . . . . . . . . . . . . . . . . . . . . . 36
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . 36
Coil Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Cleaning Cooling Coil . . . . . . . . . . . . . . . . . . . 36
Cleaning Insulation . . . . . . . . . . . . . . . . . . . . . 36
Replacing Filters . . . . . . . . . . . . . . . . . . . . . . . 37
START-UP CHECKLIST. . . . . . . . . . . . . . . . . CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can
be hazardous due to system pressure and electrical
components. Only trained and qualified service personnel
should install, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance
functions of cleaning coils and filters and replacing filters. All
other operations should be performed by trained service
personnel. When working on air-conditioning equipment,
observe precautions in the literature, tags and labels
attached to the unit, and other safety precautions that may
apply.
Follow all safety codes, including ANSI (American National
Standards Institute) Z223.1. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations. Have
fire extinguisher available for all brazing operations.
It is important to recognize safety information. This is the
safety-alert symbol
unit and in instructions or manuals, be alert to the potential
for personal injury.
Understand the signal words DANGER, WARNING,
CAUTION, and NOTE. These words are used with the
safety-alert symbol. DANGER identifies the most serious
hazards which will result in severe personal injury or death.
WARNING signifies hazards which could result in personal
injury or death. CAUTION is used to identify unsafe
. When you see this symbol on the
2-23
