- Page 1 INSTALLATION, USE AND MAINTENANCE MANUAL Snakky Max English DOC. NO. H 239U 00 EDITION 1 2004-07...
- Page 3 Targhetta di identificazione Identification label Valbrembo, 01/01/2012 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY DÉCLARATION DE CONFORMITÉ KONFORMITÄTSERKLÄRUNG DECLARACIÓN DE CONFORMIDAD DECLARAÇÃO DE CONFORMIDADE VERKLARING VAN OVEREENSTEMMING Italiano Si dichiara che la macchina, descritta nella targhetta di identificazione, è Direttive europee Sostituita da conforme alle disposizioni legislative delle Direttive Europee elencate a lato e suc- European directives...
- Page 4 Declaration of conformity for scrapping T�� s��b�� s���s ���� ��� ������� ��� ��� be disposed of as common waste, but it must b� ��s��s�� �� �s �� �s �s��b��s��� b� ��� T�� ����������� �� ���������� ���� ��� �������� ������ 2002/96/CE (Waste Electrical and Electronics ��v�s ���...
-
Page 5: Table Of Contents
PROGRAMMING MENU - SUMMARY PAGE 31 MANUAL RELEASE PAGE 11 WIRING DIAGRAM PAGE 58 OPERATING MODES PAGE 12 USER INTERFACE PAGE 12 DIRECT SELECTIONS PAGE 12 NORMAL OPERATING MODE PAGE 12 © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 6: Introduction
IN Case Of faIlURe In most cases, any technical problems are corrected by INTRODUCTION small repair operations; however, before contacting the manufacturer we recommend that this manual be read This technical documentation is part and parcel of carefully. the machine and must always follow the machine in Should there be serious failures or malfunctions, contact case it is moved or ownership is transferred, so as the following:... -
Page 7: Using The Vending Machine
- insulating materials should be recovered by qualified companies; - the gas inside the cooling unit, regardless of the type (see the identification plate), should be recovered by qualified companies by means of special equipment. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 8: Technical Specifications
(machine completely empty) °C the following power consumption levels resulted: - Hourly stand-by power consumption The above power consumption calculated from average data should only be taken as an indication. Fig. 3 © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 9: Changeable Combination Lock
Generally, only the use key (silver) is used, while the combination change keys (gold) can be kept as spares. Do not use the change key for normal opening, as it may damage the lock. Fig. 4 © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 10: Loading And Cleaning
Some bottle types can be dispensed without using the supports. Most bottles can be dispensed without using any special accessories, loading the bottles up side down, so that the © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 11: Hygiene And Cleaning
Before any maintenance operation always switch the machine off. The integrity of the machine and compliance with the standards of the relevant systems must be checked at least once a year by qualified personnel. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 12: Loading Products
Fold the seal towards the front of the unit and upwards before inserting the product in the spiral. More fragile products must be placed on the lower trays to prevent damage when they drop. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 13: Installation
- loosen the fastening screws and adjust the selector opening lever; - to aid installation the coin mechanism support plate can be lifted and rotated. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 14: Connection To The Power Supply
Do not use adapters, multiple sockets and/or exten- sions. THE MANUFACTURER DECLINES ALL RESPONSI- BILITY FOR ANY DAMAGE CAUSED BY NON-COM- PLIANCE WITH THE ABOVE MENTIONED PRECAU- TIONS. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 15: Internal Components
The power supply unit, mounted in the lower section of the cabinet, contains the relay card which activates the com- pressor, the protection fuses and the switch on the pay- ment system door. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 16: Operating Modes
Price button menu, or to exit from the current command. is used to access directly the price/selection combination of time band 0, if the function is enabled in the “Programming” menu. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 17: Statistics
Press the confirm button “ ”, and the message “Con- firm?” starts blinking. Press the confirm button “ ”, the message “Working” is displayed for a few seconds and all statistics are reset. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 18: Test
With this function the counters that control the pre-alarms are reset. EVADTS TRANSFER When activating this function, the machine awaits the connection with a device to acquire the EVADTS statis- tics. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 19: Technician Menu
Pin code Contrast control Pre-alarms Thresholds Cold paramet. Temperature Counters Enable cold unit Threshold association Enable Food control Temperature log Number in bank Miscellaneous Password Energy saving Menu masking Fluorescent lamps © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 20: Present Failures
With this function the failed motors are displayed for approximately 1 second. Scrolling through all failed motors is automatic. Note: By restarting the machine any blocked motors are de- tected as not present. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 21: Programming The Parameters
- U-Key VALIDATORS When the “Validat. Lines” (line setting) function of the “technician” menu is displayed, the value of the 6 validator coin lines, A to F, can be changed. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... - Page 22 Any credit exceeding the amount programmed with this X.XXX function will be cashed. Press the confirm button “ ”, these values will start blinking and can then be modified as necessary. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00...
- Page 23 After a failure to the motors of these selections, the decide whether to keep or return the entire amount by machine configuration procedure in the “Spiral/Selec- activating/deactivating the “Virtual change return” option. tion” menu must be followed. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00...
- Page 24 In these cases the machine can be programmed to: - set a rotation time for each spiral for settling beyond the normal rotation; - return or not the paid amount; - block further selections for the involved spiral. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00...
- Page 25 LCD CONTRAST CONTROL This function is used for adjusting the display contrast from 5% to 99% (default). © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00...
-
Page 26: Statistics
Total value of dispensing paid differently; for example also other types of payment (C.P.C., token). Audit 10 Manual filling Money inserted in the coin mechanism through the manual filling function. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 27: Test
If fitted on the machine, the 5 buttons are checked sequentially. Press the button requested on the display; if it works correctly the request for the next button is presented. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 28: Machine Information
“master GSM”. blinking. Press the confirm key “ ” after changing the fourth digit; the value is stored and the display indicates “0000” again. © by NECTA VENDING SOLUTIONS SpA 0407 239 - 00... -
Page 29: Maintenance
(UpKey, Personal Computer or similar) the machine man- agement software can be updated without replacing the EPROM. Warning! When downloading the software it is advisable to discon- nect the motor connectors from the CPU board (J1 e J2). © by NECTA VENDING SOLUTIONS SpA 0407 239 -00... -
Page 30: Configuring The Trays
If necessary slide the ejector along the spiral wire to locate the most appropriate position according to the product being dispensed. Fig. 19 1 - Spirals 2 - Ejectors © by NECTA VENDING SOLUTIONS SpA 0407 239 -00... -
Page 31: Changing The Number Of Trays
(1-6), the second figure refers to the spiral number, counting from the left (0-5). The selection number to which the motor is connected will therefore be formed by the tray number plus the wire code number. © by NECTA VENDING SOLUTIONS SpA 0407 239 -00... -
Page 32: Power Supply Unit
- remove the anti-theft grille Fig. 26 - undo the fastening screws from the product dispensing Evaporator compartment and remove it Condenser - For reassembly, proceed in the reverse order. Dispensing compartment © by NECTA VENDING SOLUTIONS SpA 0407 239 -00... - Page 62 ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________...
-
Page 63: Wiring Diagram
OPEN HATCH SWITCH OUT/R BOARD LIQUID CRYSTAL DISPLAY PUSH-BUTTON BOARD M1-... RELEASE MOTOR STARTER DISPENSING COMPARTMENT LOCK MOTOR C.P.U. BOARD CONNECTOR FOR MDB COIN MECH TRANSFORMER PROGRAMMING ACCESS MICROSWITCH TX..DELAYED FUSE (X=COURRENT) © by NECTA VENDING SOLUTIONS SpA 0110 239-00... - Page 64 sx41900...
