Necta StarFood Installation, Operating And Maintenance Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

INSTALLATION, OPERATING AND MAINTENANCE MANUAL

StarFood

English

DOC. NO.

H 171U 01

EDITION 2 2001-10

Table of Contents

Summary of Contents for Necta StarFood

Page 1 INSTALLATION, OPERATING AND MAINTENANCE MANUAL StarFood English DOC. NO. H 171U 01 EDITION 2 2001-10...
Page 3 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY DÉCLARATION DE CONFORMITÉ KONFORMITÄTSERKLÄRUNG DECLARACIÓN DE CONFORMIDAD DECLARAÇÃO DE CONFORMIDADE VERKLARING VAN OVEREENSTEMMING INTYG OM ÖVERENSSTÄMMELSE OVERENSSTEMMELSESERKLÆRING Valbrembo, 03/05/2001 Dichiara che la macchina descritta nella targhetta di identificazione, è conforme alle disposizioni legislative delle direttive: 89/392, 89/336, 73/23 CEE e successive modifiche ed integrazioni.
Page 5: Table Of Contents
FILLER MENU - SUMMARY PAGE 27 CHANGE TUBES CONTROL PAGE 12 ADJUSTING THE AIRFLOW PAGE 12 TECHNICIAN MENU - SUMMARY PAGE 33 ANTI-TAMPERING CHECK PAGE 13 WIRING DIAGRAM PAGE 51 TEST PAGE 13 © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 6: Introduction
Serial number Product code Model Frequency Type Operating voltage Current Absorbed power Refrigeration system type Refrigeration gas amount © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 7: Positioning The Vending Machine
The machine should be positioned with a maximum incli- room temperature is between 0°C and 32°C. nation of 2°. If necessary provide proper levelling by way of the adjust- able feet included. A front foot panel is available as accessory. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 8: Technical Specifications
- Liquid Crystal Display for each drum to indicate the Fan-forced evaporator sales price. Programmable defrosting cycle - Cooling unit with electronic temperature control. NOISE LEVEL The continuous, weighted equivalent acoustic pressure level is below 70 dB. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 9: Loading And Cleaning
For the following 10 minutes the closing attempts will be repeated every minute, then the machine will lock. The closing attempts are indicated by a sound and on the display. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 10: Internal Components
The message “Loading with the door open” is indicated on RS 232 serial port the display and dispensing is disabled. Programming access button Failure reset button Programming switch Liquid crystal display Coin chute Coin return lever © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 11: Hygiene And Cleaning
F.I.F.O. it will be necessary to fill all sectors. For loading, the instructions indicated on the inside of the door must be followed, particularly ensuring that: © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 12: Routine Maintenance
Clean varnished parts with silicone wax. Switch off the machine in the event of failure or malfunction. Any repairs should be carried out exclu- sively by qualified personnel using original spare parts only. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 13: Installation
The electrical safety of the machine is ensured only when - adjust the coin chute according to the type of coin it is correctly earthed according to the safety standards in mechanism installed. force. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 14: Operating Modes
For the following 10 minutes the closing attempts will be repeated every 60 seconds. The closing attempts are indicated by a sound and on the display. Fig. 8 © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 15: Loading
Counting is by means of a lever, operated by the passage of partitions. A sensor detects the passage of a magnet, located on the edge of each drum, identifying the home point. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 16: Filler Menu
3 - failure counter; screw. 4 - coin mechanism data. The printout will also contain the machine code, the date and the software version. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 17: Anti-Tampering Check
(full/empty/ rotation can be tested by pressing the selection buttons. expired). With these functions, pressing the loading buttons does not change the status of a drum and/or of a sector (full/ empty/expired). © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 18: Technician Menu
3 attempts of 10 seconds after opening the slider, the Cancel relative Partial machine is set out of service. Total 10 more closing attempts are made at 60 second intervals. Display counter at start-up © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 19: Programming Parameters
Check the label on the coin mechanism for the correct coin to value matching, indicating the position of the coins. By selecting one of the systems it is possible to control its functions. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 20: Drums / Sliders
Setting the amount of time for slider opening (10 sec. by When this function is enabled, disabled by default, the default). cash message is sent at the beginning of dispensing. DECIMAL POINT © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 21: Cold Parameters
COLD UNIT ENABLE the start-up phase of the machine. The cooling unit operation can be disabled. The change will apply when restarting the machine. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 22: Miscellaneous
This function is used to determine the filler menu options to be left active or to be disabled. The reference numbers of the menus do not change even if some are disabled. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 23: Test
“Working” is displayed for a few seconds. inserting any money. With this function, when pressing the selection button the status of a drum and/or of a sector is changed (full/ empty/expired). © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 24: Programmer
INITIALISING Confirm? CONFIGURATION CONFIG. END Exit from the configuration menu The software restarts from address 0000 (as at machine start-up) Fig. 11 1 - Connector 2 - Programmer holder 3 - Programmer © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 25: Maintenance
- 24 V DC power supply to board - BDV connector - MDB connector - Coin mechanism setting Minidip - Connector not used - Buzzer - RS232 connector to programmer - Connector not used - Validator connector © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 26: Actuation Board
2 drum magnet 3 drum magnet 4 drum magnet 5 drum magnet 6 drum magnet 7 drum magnet 8 drum magnet 9 drum magnet 10 drum magnet 11 drum magnet 12 © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 27: Self-Diagnosis Function
In the event of a short-circuit the value 41.0 is displayed. “ ” to advance to the next check. At the end of the test cycle, switch the machine off and place Minidip 1 back to the OFF position. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 28: Drum Maintenance
(see Fig. 9) on the slider guide must be adjusted partitioning (see Fig. 15) can be assembled. again. Undo the stop screw, using a Phillips screwdriver, and move it to the new position. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 29: Disassembling The Drum Stack
However, the software ensures that the defrosting cycle does not exceed 10 minutes. Fig. 17 1 - Shaft 2 - Shaft supports 3 - Hexagon head screws - Re-assembly will be done in the reverse order. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 30: Maintenance And Cleaning
When the protective casing is fitted, only the fuses and the main switch are accessible. When replacing any fuses the machine must be discon- nected from the power supply. © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 55: Wiring Diagram
OPEN DOOR MICROSWITCH OUT/R BOARD OPEN PAYMENT COMPT. MICROSWITCH PUSH-BUTTON BOARD DRUM MOTOR SP1-10 LOADING BUTTONS MS1-.. SLIDER MICROSWITCH STARTER COMPRESSOR C.P.U. BOARD TRANSFORMER NTC1 REFRIG. BOX TEMPERATURE PROBE TX..DELAYED FUSE (X=COURRENT) © by NECTA VENDING SOLUTIONS SpA 0110 171-01...
Page 56 NECTA VENDING SOLUTIONS SpA...
Page 57 Star ood...
Page 58 NECTA VENDING SOLUTIONS SpA...
Page 59 Star ood...
Page 63 The Manufacturer reserves the right to modify, without prior notice, the characteristics of the equipment described in this publication; and further declines to accept any responsibility for any inaccuracies contained in this publication which can be ascribed to printing and/or transcription errors. All instructions, drawings, tables and information contained in this publication are confidential and can neither be repro- duced completely nor in part, nor be transmitted to third parties without the written permit of the Manufacturer, who has the sole ownership.
