BA01247D/06/EN/03.20
71479741
2020-06-01
Valid as of version
01.01.zz (Device firmware)
Products
Operating Instructions
Proline Cubemass C 100
PROFIBUS DP
Coriolis flowmeter
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Proline Cubemass C 100 PROFIBUS DP

Summary of Contents for Endress+Hauser Proline Cubemass C 100 PROFIBUS DP

  • Page 1 Products Solutions Services BA01247D/06/EN/03.20 71479741 2020-06-01 Valid as of version 01.01.zz (Device firmware) Operating Instructions Proline Cubemass C 100 PROFIBUS DP Coriolis flowmeter...
  • Page 2 • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser Sales Center will supply you with current information and updates to these instructions. Endress+Hauser...

  • Page 3: Table Of Contents

    Proline Cubemass C 100 PROFIBUS DP Table of contents Table of contents Mounting the measuring device ... 24 About this document ....6 6.2.1...
  • Page 4 10.5.1 Using the parameter to enter the 13.3 Endress+Hauser services ....102 access code ....71 10.5.2 Calculated values .
  • Page 5 Proline Cubemass C 100 PROFIBUS DP Table of contents 16.6 Performance characteristics ... . . 112 16.7 Installation ......116 16.8 Environment .

  • Page 6: About This Document

    About this document Proline Cubemass C 100 PROFIBUS DP About this document Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.

  • Page 7: Symbols For Certain Types Of Information

    • W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Detailed list of the individual documents along with the documentation code →...

  • Page 8: Standard Documentation

    About this document Proline Cubemass C 100 PROFIBUS DP 1.3.1 Standard documentation Document type Purpose and content of the document Technical Information Planning aid for your device The document contains all the technical data on the device and provides an overview of the accessories and other products that can be ordered for the device.

  • Page 9: Safety Instructions

    Proline Cubemass C 100 PROFIBUS DP Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.

  • Page 10: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.

  • Page 11: Product Safety

    It meets general safety standards and legal requirements. It also complies with the EU directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device.

  • Page 12: Product Description

    Product description Proline Cubemass C 100 PROFIBUS DP Product description The device consists of a transmitter and a sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. Product design 3.1.1 Device version with PROFIBUS DP communication protocol A0023153 ...

  • Page 13: Incoming Acceptance And Product

    Is the envelope present with accompanying documents? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! The Technical Documentation is available via the Internet or via the Endress+Hauser Operations App, see the "Product identification"...

  • Page 14: Transmitter Nameplate

     8 sections • The W@M Device Viewer: enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. 4.2.1...

  • Page 15: Sensor Nameplate

    Proline Cubemass C 100 PROFIBUS DP Incoming acceptance and product identification 4.2.2 Sensor nameplate 3 4 5 6 Order code: Ser. no.: Ext. ord. cd.: Size: Ptest = Material: 0044 Patents Date: 322541-0000 13 14 A0013907  3 Example of a sensor nameplate...

  • Page 16: Symbols On Measuring Device

    Incoming acceptance and product identification Proline Cubemass C 100 PROFIBUS DP 4.2.3 Symbols on measuring device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Reference to documentation Refers to the corresponding device documentation.

  • Page 17: Storage And Transport

    Proline Cubemass C 100 PROFIBUS DP Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.

  • Page 18: Measuring Devices With Lifting Lugs

    Storage and transport Proline Cubemass C 100 PROFIBUS DP 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device.

  • Page 19: Installation

    Proline Cubemass C 100 PROFIBUS DP Installation Installation Installation conditions 6.1.1 Mounting position Mounting location A0028772 To prevent measuring errors arising from accumulation of gas bubbles in the measuring tube, avoid the following mounting locations in the pipe: • Highest point of a pipeline.
  • Page 20 Installation Proline Cubemass C 100 PROFIBUS DP Ø orifice plate, pipe restriction [mm] [in] [mm] [in] ¹⁄₂₄ 0.03 ¹⁄₁₂ 0.06 ¹⁄₈ 0.12 ¹⁄₄ 0.20 Orientation The direction of the arrow on the sensor nameplate helps you to install the sensor according to the flow direction (direction of medium flow through the piping).

  • Page 21: Environmental And Process Requirements

    Proline Cubemass C 100 PROFIBUS DP Installation 6.1.2 Environmental and process requirements Ambient temperature range Measuring device • –40 to +60 °C (–40 to +140 °F) • Order code for "Test, certificate", option JM: –50 to +60 °C (–58 to +140 °F) ‣...

  • Page 22: Special Mounting Instructions

    Installation Proline Cubemass C 100 PROFIBUS DP Heating NOTICE Electronics can overheat due to elevated ambient temperature! ‣ Observe maximum permitted ambient temperature for the transmitter . ‣ Depending on the fluid temperature, take the device orientation requirements into account .
  • Page 23 Proline Cubemass C 100 PROFIBUS DP Installation RUPTURE DISK A0029940 Rupture disk label Wall mounting WARNING Incorrect sensor mounting Risk of injury if measuring tube breaks ‣ The sensor should never be installed in a pipe in a way that it is freely suspended ‣...

  • Page 24: Mounting The Measuring Device

    Installation Proline Cubemass C 100 PROFIBUS DP 8 mm A0019768  6 Mounting kit for Cubemass mounting plate 1 x Cubemass mounting plate 4 x screw M5 x 8 4 x grommet Zero point adjustment All measuring devices are calibrated in accordance with state-of-the-art technology.

  • Page 25: Turning The Display Module

    Proline Cubemass C 100 PROFIBUS DP Installation 1. Ensure that the direction of the arrow on the nameplate of the sensor matches the flow direction of the fluid. 2. Install the measuring device or turn the transmitter housing so that the cable entries do not point upwards.

  • Page 26: Post-Installation Check

    Installation Proline Cubemass C 100 PROFIBUS DP Post-installation check Is the device undamaged (visual inspection)?  Does the measuring device conform to the measuring point specifications? For example: • Process temperature →  117  • Process pressure (refer to the section on "Pressure-temperature ratings" in the "Technical Information"...

  • Page 27: Electrical Connection

    Proline Cubemass C 100 PROFIBUS DP Electrical connection Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.

  • Page 28: Terminal Assignment

    Electrical connection Proline Cubemass C 100 PROFIBUS DP Signal damping Max. 9 dB over the entire length of the cable cross-section Shield Copper braided shielding or braided shielding with foil shield. When grounding the cable shield, observe the grounding concept of the plant.

  • Page 29: Pin Assignment, Device Plug

    Proline Cubemass C 100 PROFIBUS DP Electrical connection A0022716  7 PROFIBUS DP terminal assignment Power supply: DC 24 V PROFIBUS DP Terminal number Order code Power supply Output "Output" 2 (L-) 1 (L+) 26 (RxD/TxD-P) 27 (RxD/TxD- Option L DC 24 V Order code for "Output":...

  • Page 30: Preparing The Measuring Device

    Electrical connection Proline Cubemass C 100 PROFIBUS DP 7.2.5 Preparing the measuring device NOTICE Insufficient sealing of the housing! Operational reliability of the measuring device could be compromised. ‣ Use suitable cable glands corresponding to the degree of protection. 1. Remove dummy plug if present.
  • Page 31 Proline Cubemass C 100 PROFIBUS DP Electrical connection 8 mm 8 mm 3 mm 10 (0.4) mm (in) A0017844  9 Device versions with connection examples Cable Device plug for signal transmission Device plug for supply voltage For device version with device plug: follow step 6 only.

  • Page 32: Ensuring Potential Equalization

    Electrical connection Proline Cubemass C 100 PROFIBUS DP 7.3.2 Ensuring potential equalization Requirements No special measures for potential equalization are required. For devices intended for use in hazardous locations, please observe the guidelines in the Ex documentation (XA). Special connection instructions 7.4.1...

  • Page 33: Enabling The Terminating Resistor

    Proline Cubemass C 100 PROFIBUS DP Electrical connection Setting the address OFF ON - Software addressing - Write protection - Not used A0021265  11 Addressing using DIP switches on the I/O electronics module 1. Depending on the housing version, loosen the securing clamp or fixing screw of the housing cover.

  • Page 34: Ensuring The Degree Of Protection

    Electrical connection Proline Cubemass C 100 PROFIBUS DP 390 Ω DIP 1 OFF ON Bus polarisation DIP 2 220 Ω Bus termination Bus polarisation Not used DIP 3 390 Ω A0021274  12 Termination using DIP switches on the I/O electronics module (for baud rates < 1.5 MBaud)
  • Page 35 Proline Cubemass C 100 PROFIBUS DP Electrical connection Are all the cable glands installed, firmly tightened and leak-tight? Cable run with "water trap"  →  34? Depending on the device version: are all the device plugs firmly tightened →  30? ...

  • Page 36: Operation Options

    Operation options Proline Cubemass C 100 PROFIBUS DP Operation options Overview of operating options A0017760 Computer with Web browser (e.g. Internet Explorer) or with "FieldCare" operating tool Automation system, e.g. "RSLogix" (Rockwell Automation) and work station for measuring device operation with Add-on Profile Level 3 for "RSLogix 5000"...

  • Page 37: Structure And Function Of The Operating Menu

    Proline Cubemass C 100 PROFIBUS DP Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: "Description of Device Parameters" document supplied with the device→  125...

  • Page 38: Operating Philosophy

    Operation options Proline Cubemass C 100 PROFIBUS DP 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (operator, maintenance etc.). Each user role contains typical tasks within the device lifecycle. Menu/parameter User role and tasks...

  • Page 39: Displaying The Measured Values Via The Local Display (Optionally Available)

    Proline Cubemass C 100 PROFIBUS DP Operation options Displaying the measured values via the local display (optionally available) 8.3.1 Operational display The local display is optionally available: Order code for "Display; operation", option B ""4-line, illuminated; via communication". X X X X X X X 1120.50...

  • Page 40: User Roles And Related Access Authorization

    Operation options Proline Cubemass C 100 PROFIBUS DP • Density • Reference density Temperature Totalizer  The measurement channel number indicates which of the three totalizers is displayed. Measurement channel numbers Symbol Meaning Measurement channel 1 to 4 The measurement channel number is displayed only if more than one channel is present for the same measured variable type (e.g.

  • Page 41: Access To The Operating Menu Via The Web Browser

    Proline Cubemass C 100 PROFIBUS DP Operation options Access to the operating menu via the Web browser 8.4.1 Function range Thanks to the integrated Web server, the device can be operated and configured via a Web browser and via a service interface (CDI-RJ45) . In addition to the measured values, status information on the device is also displayed and allows the user to monitor the status of the device.

  • Page 42: Establishing A Connection

    Operation options Proline Cubemass C 100 PROFIBUS DP 8.4.3 Establishing a connection Via service interface (CDI-RJ45) Preparing the measuring device Configuring the Internet protocol of the computer The following information refers to the default Ethernet settings of the device. IP address of the device: 192.168.1.212 (factory setting) 1.

  • Page 43: Logging On

    Proline Cubemass C 100 PROFIBUS DP Operation options 2. Enter the IP address of the Web server in the address line of the Web browser: 192.168.1.212  The login page appears. 2 3 4 A0029417 Picture of device Device name...

  • Page 44: User Interface

    Operation options Proline Cubemass C 100 PROFIBUS DP 8.4.5 User interface A0032879 Picture of device Device name Device tag Status signal Current measured values Navigation area Local display language Header The following information appears in the header: • Device name •...

  • Page 45: Disabling The Web Server

    Proline Cubemass C 100 PROFIBUS DP Operation options Functions Meaning Configuration and checking of all the parameters required for establishing the connection to Network the measuring device: configuration • Network settings (e.g. IP address, MAC address) • Device information (e.g. serial number, firmware version)

  • Page 46: Access To The Operating Menu Via The Operating Tool

    Operation options Proline Cubemass C 100 PROFIBUS DP 1. Select the Logout entry in the function row.  The home page with the Login box appears. 2. Close the Web browser. 3. If no longer needed: Reset modified properties of the Internet protocol (TCP/IP) →  42.

  • Page 47: Fieldcare

    Proline Cubemass C 100 PROFIBUS DP Operation options Via service interface (CDI) A0014019 Service interface (CDI = Endress+Hauser Common Data Interface) of the measuring device Commubox FXA291 Computer with FieldCare operating tool with COM DTM CDI Communication FXA291 Via service interface (CDI-RJ45)
  • Page 48 Operation options Proline Cubemass C 100 PROFIBUS DP Typical functions: • Configuring parameters of transmitters • Loading and saving device data (upload/download) • Documentation of the measuring point • Visualization of the measured value memory (line recorder) and event logbook...

  • Page 49: Devicecare

    DeviceCare Function scope Tool to connect and configure Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S Source for device description files See information →...

  • Page 50: System Integration

    System integration Proline Cubemass C 100 PROFIBUS DP System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.01.zz • On the title page of the Operating Instructions • On the transmitter nameplate • Firmware version Diagnostics →...

  • Page 51: Profile Gsd

    Proline Cubemass C 100 PROFIBUS DP System integration Manufacturer-specific GSD ID number File name PROFIBUS DP 0x1561 EH3x1561.gsd The fact that the manufacturer-specific GSD should be used is specified in the Ident number selector parameter by selecting the Manufacturer option.

  • Page 52: Integration Into A Profibus Network

    System integration Proline Cubemass C 100 PROFIBUS DP Integration into a PROFIBUS network 9.3.1 Block model • Physical block • Function blocks • Analog Input Block • Analog Output Block • Discrete Input Block • Discrete Output Block • Totalizer Block Technical values for the individual blocks →...

  • Page 53: Totalizer Control Set_Tot

    Proline Cubemass C 100 PROFIBUS DP System integration Channel Measured variable 1056 Exciter current 0 1057 Exciter current 1 1440 Sensor integrity Analog Output 1 to 3 (AO) Channel Measured variable External pressure External temperature External reference density The compensation variables must be transmitted to the device in the SI basic unit.

  • Page 54: Cyclic Data Transmission

    System integration Proline Cubemass C 100 PROFIBUS DP Cyclic data transmission Cyclic data transmission when using the device master file (GSD). 9.4.1 Block model The block model shows which input and output data the measuring device makes available for cyclic data exchange. Cyclic data exchange takes place with a PROFIBUS master (Class 1), e.g.
  • Page 55 Proline Cubemass C 100 PROFIBUS DP System integration AI module (Analog Input) Transmit an input variable from the measuring device to the PROFIBUS master (Class 1). The selected input variable, along with the status, is cyclically transmitted to the PROFIBUS Master (Class 1) via the AI module. The input variable is depicted in the first four bytes in the form of a floating point number as per the IEEE 754 standard.
  • Page 56 System integration Proline Cubemass C 100 PROFIBUS DP TOTAL module Transmit a totalizer value from the measuring device to the PROFIBUS master (Class 1). A selected totalizer value, along with the status, is cyclically transmitted to a PROFIBUS Master (Class 1) via the TOTAL module. The totalizer value is depicted in the first four bytes in the form of a floating point number as per the IEEE 754 standard.
  • Page 57 Proline Cubemass C 100 PROFIBUS DP System integration Data structure Output data of SETTOT Byte 1 Control variable 1 Input data of TOTAL Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Measured value: floating point number (IEEE 754)
  • Page 58 System integration Proline Cubemass C 100 PROFIBUS DP standard. The fifth byte contains standardized status information pertaining to the compensation value. Three Analog Output blocks are available (slot 12 to 14). Assigned compensation values A compensation value is permanently assigned to the individual Analog Output blocks.
  • Page 59 Proline Cubemass C 100 PROFIBUS DP System integration Data structure Input data of Discrete Input Byte 1 Byte 2 Discrete Status DO module (Discrete Output) Transmit discrete output values from the PROFIBUS master (Class 1) to the measuring device. Discrete output values are used by the PROFIBUS master (Class 1) to enable and disable device functions.

  • Page 60: Commissioning

    Commissioning Proline Cubemass C 100 PROFIBUS DP Commissioning 10.1 Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist→  26 • "Post-connection check" checklist→  34 10.2...

  • Page 61: Defining The Tag Name

    Proline Cubemass C 100 PROFIBUS DP Commissioning 10.4.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
  • Page 62 Commissioning Proline Cubemass C 100 PROFIBUS DP Parameter overview with brief description Parameter Description Selection Factory setting Mass flow unit Select mass flow unit. Unit choose list Country-specific: • kg/h Result • lb/min The selected unit applies for: • Output •...
  • Page 63 Proline Cubemass C 100 PROFIBUS DP Commissioning Parameter Description Selection Factory setting Temperature unit Select temperature unit. Unit choose list Country-specific: • °C Result • °F The selected unit applies for: • Electronic temperature parameter (6053) • Maximum value parameter (6051) •...

  • Page 64: Selecting And Setting The Medium

    Commissioning Proline Cubemass C 100 PROFIBUS DP 10.4.3 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Medium selection ‣ Medium selection →...

  • Page 65: Configuring Communication

    Proline Cubemass C 100 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Select medium – Select medium type. • Liquid Liquid • Gas Select gas type The Gas option is selected in Select measured gas type.
  • Page 66 Commissioning Proline Cubemass C 100 PROFIBUS DP Navigation "Setup" menu → Communication ‣ Communication →  66 Device address Parameter overview with brief description Parameter Description User entry Factory setting Device address Enter device address. 0 to 126 Endress+Hauser...

  • Page 67: Configuring The Analog Inputs

    Proline Cubemass C 100 PROFIBUS DP Commissioning 10.4.5 Configuring the analog inputs The Analog inputs submenu guides the user systematically to the individual Analog input 1 to n submenu. From here you get to the parameters of the individual analog input.
  • Page 68 Commissioning Proline Cubemass C 100 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry Fail safe type – Select the failure mode. • Fail safe value • Fallback value • Off Fail safe value In Fail safe type parameter, Specify the values to be output...

  • Page 69: Configuring The Low Flow Cut Off

    Proline Cubemass C 100 PROFIBUS DP Commissioning 10.4.6 Configuring the low flow cut off The Low flow cut off submenu contains the parameters that must be set in order to configure the low flow cut off. Navigation "Setup" menu → Low flow cut off ‣...

  • Page 70: Configuring The Partial Filled Pipe

    Commissioning Proline Cubemass C 100 PROFIBUS DP 10.4.7 Configuring the partial filled pipe detection The Partially filled pipe detection submenu contains parameters that have to be set for configuring empty pipe detection. Navigation "Setup" menu → Partially filled pipe detection ‣...

  • Page 71: Advanced Settings

    Proline Cubemass C 100 PROFIBUS DP Commissioning 10.5 Advanced settings The Advanced setup submenu together with its submenus contains parameters for specific settings. The number of submenus can vary depending on the device version, e.g. viscosity is available only with the Promass I.
  • Page 72 Commissioning Proline Cubemass C 100 PROFIBUS DP Navigation "Setup" menu → Advanced setup → Calculated values ‣ Calculated values ‣ Corrected volume flow calculation →  72 Corrected volume flow calculation External reference density →  72 Fixed reference density →...

  • Page 73: Carrying Out A Sensor Adjustment

    Proline Cubemass C 100 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Linear expansion coefficient The Calculated reference Enter linear, medium-specific Signed floating-point density option is selected in expansion coefficient for number the Corrected volume flow calculating the reference calculation parameter density.

  • Page 74: Configuring The Totalizer

    Commissioning Proline Cubemass C 100 PROFIBUS DP Parameter overview with brief description Parameter Description Selection / User interface Factory setting Zero point adjustment control Start zero point adjustment. • Cancel Cancel • Busy • Zero point adjust failure • Start Progress Shows the progress of the process.

  • Page 75: Using Parameters For Device Administration

    Proline Cubemass C 100 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection Factory setting Totalizer operation mode In the Assign process variable Select totalizer calculation • Net flow total Net flow total parameter, one of the mode. • Forward flow total following options is selected: •...

  • Page 76: Protecting Settings From Unauthorized

    Commissioning Proline Cubemass C 100 PROFIBUS DP Navigation "Diagnostics" menu → Simulation ‣ Simulation →  76 Assign simulation process variable →  76 Value process variable Simulation device alarm →  76 Simulation diagnostic event →  76 Parameter overview with brief description...

  • Page 77: Write Protection Via Access Code

    Proline Cubemass C 100 PROFIBUS DP Commissioning 10.7.1 Write protection via access code With the customer-specific access code, access to the measuring device via the Web browser is protected, as are the parameters for the measuring device configuration. Navigation "Setup" menu → Advanced setup → Administration → Define access code ‣...
  • Page 78 Commissioning Proline Cubemass C 100 PROFIBUS DP OFF ON - Software addressing - Write protection - Not used A0021262 Setting the write protection switch on the main electronics module to the On position enables hardware write protection. Setting the write protection switch on the main electronics module to the Off position (factory setting) disables hardware write protection.

  • Page 79: Operation

    Proline Cubemass C 100 PROFIBUS DP Operation Operation 11.1 Reading the device locking status Device active write protection: Locking status parameter Navigation "Operation" menu → Locking status Function scope of "Locking status" parameter Options Description Hardware locked The write protection switch (DIP switch) for hardware locking is activated on the I/O electronic module.
  • Page 80 Operation Proline Cubemass C 100 PROFIBUS DP Volume flow →  80 Corrected volume flow →  80 Density →  80 Reference density →  80 →  80 Temperature Pressure value →  81 Concentration →  81 Target mass flow →...

  • Page 81: Totalizer" Submenu

    Proline Cubemass C 100 PROFIBUS DP Operation Parameter Prerequisite Description User interface Pressure value – Displays either a fixed or external Signed floating-point pressure value. number Dependency The unit is taken from the Pressure unit parameter (→  63). Concentration...

  • Page 82: Adapting The Measuring Device To The Process

    Operation Proline Cubemass C 100 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description User interface Totalizer value 1 to n One of the following options is selected Displays the current totalizer counter Signed floating-point in the Assign process variable value.
  • Page 83 Proline Cubemass C 100 PROFIBUS DP Operation Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Control Totalizer 1 to n In the Assign process variable Control totalizer value. • Totalize Totalize parameter, one of the • Reset + hold following options is selected: •...

  • Page 84: Diagnostics And Troubleshooting

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting 12.1 General troubleshooting For local display Problem Possible causes Remedial action Local display dark and no output Supply voltage does not match that Apply the correct supply voltage signals specified on the nameplate.

  • Page 85: Diagnostic Information Via Light Emitting

    Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Problem Possible causes Remedial action No connection via PROFIBUS DP PROFIBUS DP cable incorrectly Check terminating resistor . terminated Not connecting to Web server Incorrect setting for the Ethernet 1. Check the properties of the interface of the computer Internet protocol (TCP/IP) .

  • Page 86: Diagnostic Information On Local Display

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display.
  • Page 87 Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. A0013961 • A diagnostic message is generated. Warning Measurement is resumed. The signal outputs and totalizers are not affected. A diagnostic message is generated.

  • Page 88: Calling Up Remedial Measures

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage...
  • Page 89 Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F)

  • Page 90: Calling Up Remedy Information

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Diagnostic information The fault can be identified using the diagnostic information. The short text helps you by providing information about the fault. Diagnostic information Diagnostic code Status signal Diagnostic number Short text ↓...
  • Page 91 Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Displaying the measured value status If the Analog Input, Digital Input and Totalizer function blocks are configured for cyclic data transmission, the device status is coded as per PROFIBUS Profile Specification 3.02 and transmitted along with the measured value to the PROFIBUS Master (Class 1) via the coding byte (byte 5).

  • Page 92: Overview Of Diagnostic Information

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Measured value status (fixed assignment) Diagnostic behavior Device diagnostics Quality Coding Category (configurable) (fixed assignment) Quality Substatus (hex) (NE107) Logbook entry only GOOD 0x80 to 0x8E – – Diagnostic information pertaining to the electronics (diagnostic no.: 200 to 399)
  • Page 93 Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Diagnostic of sensor Sensor temperature 1. Change main electronic Alarm module 2. Change sensor Sensor limit exceeded 1.
  • Page 94 Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Special event 2 Contact service Alarm Special event 6 Contact service Alarm Special event 10...

  • Page 95: Pending Diagnostic Events

    Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Partly filled pipe 1. Check for gas in process Warning 2. Adjust detection limits Input signal 1.

  • Page 96: Diagnostic List

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description User interface Factory setting Actual diagnostics 1 diagnostic event has Displays the current diagnostic Symbol for diagnostic – occurred. event along with the behavior, diagnostic diagnostic information.

  • Page 97: Filtering The Event Logbook

    Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting Navigation path "Diagnostics" menu → Event logbook → Events list To call up the measures to rectify a diagnostic event: • Via Web browser • Via "FieldCare" operating tool →  90 For filtering the displayed event messages →...

  • Page 98: 12.10 Resetting The Measuring Device

    Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Info number Info name I1397 Fieldbus: access status changed I1398 CDI: access status changed I1444 Device verification passed I1445 Device verification failed I1446 Device verification active I1447 Record application reference data...

  • Page 99: 12.10.1 Function Scope Of "Device Reset" Parameter

    Proline Cubemass C 100 PROFIBUS DP Diagnostics and troubleshooting 12.10.1 Function scope of "Device reset" parameter Options Description Cancel No action is executed and the user exits the parameter. To delivery settings Every parameter for which a customer-specific default setting was ordered is reset to this customer-specific value.
  • Page 100 Diagnostics and troubleshooting Proline Cubemass C 100 PROFIBUS DP Parameter overview with brief description Parameter Description User interface Factory setting Device tag Enter the name for the measuring point. Max. 32 characters, such as Promass 100 DP letters, numbers or special characters (e.g.

  • Page 101: 12.12 Firmware History

    "Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser Internet site: www.endress.com → Download • Specify the following details: •...

  • Page 102: Maintenance

    →  117. 13.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services. List of some of the measuring and testing equipment: →  105→  106 13.3...

  • Page 103: Repair

    • The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.

  • Page 104: Disposal

    (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste. Instead, return them to Endress+Hauser for disposal under the applicable conditions.

  • Page 105: Accessories

    Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.

  • Page 106: Service-Specific Accessories

    Accessories Description Applicator Software for selecting and sizing Endress+Hauser measuring devices: • Choice of measuring devices for industrial requirements • Calculation of all the necessary data for identifying the optimum flowmeter: e.g. nominal diameter, pressure loss, flow velocity and accuracy.

  • Page 107: Technical Data

    Proline Cubemass C 100 PROFIBUS DP Technical data Technical data 16.1 Application The measuring device is intended only for the flow measurement of liquids and gases. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.

  • Page 108: Input

    Technical data Proline Cubemass C 100 PROFIBUS DP 16.3 Input Measured variable Direct measured variables • Mass flow • Density • Temperature Calculated measured variables • Volume flow • Corrected volume flow • Reference density Measuring range Measuring ranges for liquids Measuring range full scale values ...

  • Page 109: Output

    • Operating pressure to increase accuracy (Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar S) •...
  • Page 110 Technical data Proline Cubemass C 100 PROFIBUS DP Web browser Plain text display With information on cause and remedial measures Light emitting diodes (LED) Status information Status indicated by various light emitting diodes The following information is displayed depending on the device version: •...

  • Page 111: Power Supply

    Proline Cubemass C 100 PROFIBUS DP Technical data Input values Analog output 1 to 3 (fixed assignment) (from automation system to • Pressure measuring device) • Temperature • Reference density Digital output 1 to 3 (fixed assignment) • Digital output 1: switch positive zero return on/off •...

  • Page 112: Performance Characteristics

    Technical data Proline Cubemass C 100 PROFIBUS DP Power supply failure • Totalizers stop at the last value measured. • Depending on the device version, the configuration is retained in the device memoryor in the pluggable data memory (HistoROM DAT).
  • Page 113 Proline Cubemass C 100 PROFIBUS DP Technical data Temperature ±0.5 °C ± 0.005 · T °C (±0.9 °F ± 0.003 · (T – 32) °F) Zero point stability Zero point stability [mm] [in] [kg/h] [lb/min] ¹⁄₂₄ 0.0008 0.00003 ¹⁄₁₂ 0.002 0.00007...
  • Page 114 Technical data Proline Cubemass C 100 PROFIBUS DP Mass flow (gases) ±0.25 % o.r. Density (liquids) ±0.00025 g/cm Temperature ±0.25 °C ± 0.0025 · T °C (±0.45 °F ± 0.0015 · (T–32) °F) Response time The response time depends on the configuration (damping).
  • Page 115 Proline Cubemass C 100 PROFIBUS DP Technical data o.r. = of reading It is possible to compensate for the effect by: • Reading in the current pressure measured value via the current input. • Specifying a fixed value for the pressure in the device parameters.

  • Page 116: Installation

    Technical data Proline Cubemass C 100 PROFIBUS DP 16.7 Installation Installation conditions →  19 16.8 Environment Ambient temperature →  21→  21 range Temperature tables Observe the interdependencies between the permitted ambient and fluid temperatures when operating the device in hazardous areas.

  • Page 117: Process

    Proline Cubemass C 100 PROFIBUS DP Technical data Electromagnetic • As per IEC/EN 61326 and NAMUR Recommendation 21 (NE 21) compatibility (EMC) • Complies with emission limits for industry as per EN 55011 (Class A) • Device version with PROFIBUS DP: Complies with emission limits for industry as per EN 50170 Volume 2, IEC 61784 The following applies for PROFIBUS DP: If baud rates >...
  • Page 118 Technical data Proline Cubemass C 100 PROFIBUS DP Sensor housing The sensor housing is filled with dry nitrogen gas and protects the electronics and mechanics inside. Rupture disk To guarantee the safety of the measuring device, the device version with a rupture disk with a triggering pressure of 10 to 15 bar (145 to 217.5 psi) is the standard version used.

  • Page 119: 16.10 Mechanical Construction

    Proline Cubemass C 100 PROFIBUS DP Technical data 16.10 Mechanical construction Design, dimensions For the dimensions and installation lengths of the device, see the "Technical Information" document, "Mechanical construction" section. Weight All values (weight exclusive of packaging material) refer to devices with VCO couplings.
  • Page 120 Technical data Proline Cubemass C 100 PROFIBUS DP Order code for "Housing", option A "Compact, aluminum, coated" The various cable entries are suitable for hazardous and non-hazardous areas. Cable entry/cable gland Material Cable gland M20 × 1.5 Adapter for cable entry with female thread G ½"...

  • Page 121: 16.11 Human Interface

    Proline Cubemass C 100 PROFIBUS DP Technical data Accessories Protective cover Stainless steel, 1.4404 (316L) Safety Barrier Promass 100 Housing: Polyamide Process connections • Fixed flange connections: • EN 1092-1 (DIN 2512N) flange • ASME B16.5 flange • JIS B2220 flange •...
  • Page 122 Technical data Proline Cubemass C 100 PROFIBUS DP For some work performed on the measuring device (e.g. electrical connection), it is advisable to disconnect the local display from the main electronics module: 1. Press in the side latches of the local display.

  • Page 123: 16.12 Certificates And Approvals

    The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. RCM-tick symbol The measuring system meets the EMC requirements of the "Australian Communications...

  • Page 124: 16.13 Application Packages

    The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.

  • Page 125: 16.14 Accessories

    For an overview of the scope of the associated Technical Documentation, refer to the following: • W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Standard documentation Brief Operating Instructions...
  • Page 126 Technical data Proline Cubemass C 100 PROFIBUS DP Content Documentation code INMETRO Ex nA XA01222D NEPSI Ex i XA01261D NEPSI Ex nA XA01263D Special Documentation Content Documentation code Information on the Pressure Equipment Directive SD00142D Concentration measurement SD01152D Heartbeat Technology...

  • Page 127: Index

    Proline Cubemass C 100 PROFIBUS DP Index Index Design fundamentals Maximum measured error ....115 About this document ......6 Repeatability .
  • Page 128 Index Proline Cubemass C 100 PROFIBUS DP Measuring device ......27 Input ........108...
  • Page 129 Proline Cubemass C 100 PROFIBUS DP Index Operation ......79 Setup (Menu) ......61 Setup .
  • Page 130 Index Proline Cubemass C 100 PROFIBUS DP Settings Supply voltage ......111 Adapting the measuring device to the process Surface roughness .
  • Page 131 Proline Cubemass C 100 PROFIBUS DP Index Wizard Define access code ......77 Low flow cut off ......69 Partially filled pipe detection .
  • Page 132 www.addresses.endress.com...

Table of Contents
