The Add an IKE Connection screen displays. All settings can be left at the default unless
otherwise indicated:
1. Connection Name: Enter in the name of the VPN tunnel you want to create
2. Secret: Enter in the Secret (which has to match on both ends of the tunnel)
3. Local WAN IP: Select WAN1
4. Local LAN: Select LAN
5. Remote LAN: Select remote-WAN.
6. UID: Click the UID checkbox to enable UID.
7. Local ID: Enter the IP Address of the RouteFinder's WAN IP.
8. Remote ID: Enter IP Address of the remote device that is at the other end of the VPN
tunnel.
9. Click the Save button to save your tunnel.
Note:
Make sure to check the Status box at the bottom of the screen on the left side to activate the
newly created tunnel.
