Step 2 – Packet Filters

Go to the Packet Filters screen to give the client at the other end of the VPN tunnel the

rights to access across the tunnel.

Click on From (Host/Networks) and select the remote client and remote WAN IP you are

allowing to access your network (you should already have the LAN Any Any Accept listed).

If you are not restricting what type of service, select Any for the To (Host/Network).

Click the Add button to add the Packet Filter rule.

Important Note: Do not check the Status box. When adding a user-defined rule, leave the

Status box unchecked.

Step 3 – VPN Setup

Go to the VPN > IPSec screen.

Click on the VPN Status check box to enable IPSec. Then click the Save button.

Select Add an IKE Connection by clicking the corresponding Add button.

Multi-Tech Systems, Inc. RF820/830 IPSec VPN Setup Examples – A Reference Guide

Chapter 2 – Behind NAT Setup Examples
