Icom IC-R9500 Service Manual Addendum page 260

NOTE: HOLD the adjustment condition (SG level and frequency etc.) until next ADJ item is displayed.
ADJUSTMENT ITEM
S-METER(V/U1)
[V/U1 S0 LEVEL]
[V/U1 S9 LEVEL]
[V/U1 S9+60 LEVEL]
FIELD STERNGTH METER
[V/U1 dBu -10dB]
[V/U1 dBu 0dB]
[V/U1 dBu 10dB]
[V/U1 dBu 20dB]
[V/U1 dBu 40dB]
[V/U1 dBu 60dB]
[V/U1 dBu 80dB]
S-METER(V/U2)
[V/U2 S0 LEVEL]
[V/U2 S9 LEVEL]
[V/U2 S9+60 LEVEL]
FIELD STREGTH METER
[V/U2 dBu -10dB]
[V/U2 dBu 0dB]
[V/U2 dBu 10dB]
[V/U2 dBu 20dB]
[V/U2 dBu 40dB]
[V/U2 dBu 60dB]
[V/U2 dBu 80dB]
V/U BPF LOSS
[V/U BPF1 (L) LOSS]
[V/U BPF1 (M) LOSS]
[V/U BPF1 (H) LOSS]
[V/U BPF2 (L) LOSS]
[V/U BPF2 (M2) LOSS]
ADJUSTMENT CONDITION
• Set the SG as;
Frequency : 50.1515 MHz
• Set the SG as;
Level : OFF
• Set the SG as;
Level : +34 dBu
• Set the SG as;
Level : +90 dBu
• Set the SG as;
Frequency : 50.1515 MHz
• Set the SG as;
Level : −10 dBu
• Set the SG as;
Level : 0 dBu
• Set the SG as;
Level : +10 dBu
• Set the SG as;
Level : +20 dBu
• Set the SG as;
Level : +40 dBu
• Set the SG as;
Level : +60 dBu
• Set the SG as;
Level : +80 dBu
• Set the SG as;
Frequency : 625.0215 MHz
• Set the SG as;
Level : OFF
• Set the SG as;
Level : +34 dBu
• Set the SG as;
Level : +90 dBu
• Set the SG as;
Frequency : 625.0215 MHz
• Set the SG as;
Level : −10 dBu
• Set the SG as;
Level : 0 dBu
• Set the SG as;
Level : +10 dBu
• Set the SG as;
Level : +20 dBu
• Set the SG as;
Level : +40 dBu
• Set the SG as;
Level : +60 dBu
• Set the SG as;
Level : +80 dBu
• Set the SG as;
Level : +40 dBu
• Set the SG as;
Frequency : 30.0215 MHz
• Set the SG as;
Frequency : 37.5215 MHz
• Set the SG as;
Frequency : 44.9815 MHz
• Set the SG as;
Frequency : 45.0215 MHz
• Set the SG as;
Frequency : 57.5215 MHz
OPERATION
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
4 - 12
VALUE
(Automatic
adjustment)
(Automatic
adjustment)
(Automatic
adjustment)
(Automatic
adjustment)
(Automatic
adjustment)
