Summary of Contents for Comelit HFX-700W
- Page 1 QUICK REFERENCE GUIDE MYCOMELIT: THE APP FOR PROFESSIONALS MYCOMELIT, L'APP PER IL PROFESSIONISTA FREE DOWNLOAD Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. Single-User Kit HFX-700W also available in French and Spanish...
-
Page 2: Contents Of The Package
QR code. By installing and configuring the COMELIT App on smartphone / tablet it is possible to answer video door entry calls from a local and remote network (or mobile network); in addition it is possible to make a Self activation on cameras/entrance panels and send commands to actuator modules. -
Page 3: Parts Identification
2. Parts identification 2.1 EX-B EXTERNAL UNIT 1.14 3.15 in 1.06 1.18 in 1. Hole for wall mounting 8. Adjustment trimmer (See page 13) 2. Terminal block 9. Addressing and programming DIP-switches bus line connection 10. CNF Programming confirmation button programmable RTE (local lock-release input) or 11. - Page 4 FLASHING LED: incoming call STEADY LED (WITH CALL): In communication STEADY LED (IDLE): Hands-Free mode enabled When used in conjunction with the Comelit app (available to download free of charge from Google Play or App Store) and/or the voice FLASHING LED: Incoming call...
- Page 5 2.3 1209/4 BUS POWER SUPPLY 4.17 in 3.52 in Dopo un cortocircuito,per ripristinare l'apparecchio, interrompere l'alimentazione per circa 1 minuto. To reset the operation after a short circuit,cut o mains voltage for about 1 minute. Apres un court circuit, pour remettre en fonction l'appareil, Art.1209/4 interrompre l'alimentation pendant environs une minute.
-
Page 6: System Installation
(170 m) 1,181 feet 590 feet 590 feet non-braided cable AWG18 (360 m) (180 m) (180 m) 3.1.1 Single-User Kit HFX-700W 3.1.2 Maximum Expansion Monitors in Daisy Chain connection EX-7000H EX-7000H expansion expansion expansion expansion door entry monitor door entry monitor... - Page 7 1209/4 EX-BSB EX-BSB EX-BSB expansion external unit expansion external unit expansion external unit expansion external unit expansion external unit expansion external unit 1405 1405 1405 EX-B EX-B EX-B EX-B HFX-700W...
- Page 8 Basic single-user kit STANDARD INSTALLATION EX-7000HW Comelit app router 1 2 3 4 LEAVE DEFAULT LEAVE DEFAULT SETTING SETTINGS 1209/4 LP LP L1 L1 L2 L2 L3 L3 L4 L4 110-240V EX-B Local lock release button...
- Page 9 1 2 3 4 LEAVE DEFAULT LEAVE DEFAULT SETTING LEAVE DEFAULT LEAVE DEFAULT SETTING SETTINGS SETTINGS EX-7000HW EX-7000H Comelit app router REMOVE CV5 REMOVE CV5 1 2 3 4 LEAVE DEFAULT SETTING LEAVE DEFAULT SETTINGS 1 2 3 4 REMOVE CV5...
- Page 10 Expanded single-user kit MAXIMUM EXPANSION...
- Page 11 3.2 ASSEMBLY MINI HANDSFREE WI-FI ART. EX-7000HW INTERNAL UNIT Before definitive installation of the monitors, make sure the device has good Wi-Fi signal reception; the distance between the router and monitors, and the construction materials used in the walls are factors that can affect signal quality.
- Page 12 3.3 INSTALLATION OF EXTERNAL UNIT ART. EX-B The camera must not be installed in front of light sources, or in places where the filmed subject is against the light. In dim environments, we recommend additional lighting is provided. 79° 79° 79°...
- Page 13 REMOVE TERMINAL IF NEEDED Microphone DO NOT DO NOT CHANGE CHANGE Loudspeaker ADJUST IF NEEDED...
-
Page 14: Additional Features
3.3.1 How to change the nameplate of the external unit art. EX-B 4. Additional features This Quick reference Guide contains all the basic informations to install the single-user kit. Additional features in the full manual at the web site pro.comelitgroup.com: •... -
Page 15: System Function
5. System function Press the desired key once to activate the function associated with it. „ Wait for approximately 1 sec. before pressing the same key again. Pressing the same key several times in quick succession will cancel the command. 5.1 PERFORMING CALLS 5.1.1 How to call from the external unit 5.1.2 How to answer a call from an internal unit... -
Page 16: Self Activation Function
Factory reset Reset APP 6.1 WI-FI CONNECTION STATUS By installing and configuring the COMELIT App on smartphone / tablet Access point: If the system requires wireless connection of the monitor, link the device with the local router it is possible to answer video door entry calls from a local and remote network (or mobile network);... -
Page 17: Technical Specification
Absorption during call (mA) 150-180 Absorption during communication (mA) 250-300 Network connection WLan Video encoding PAL/NTSC Wi-Fi technology Yes Compatible with Comelit app Yes 7.2 EX-B EXTERNAL UNIT Height 5.90 in Width 3.15 in Depth 1.06 in Weight 10.58 oz Wall-mounted Yes Sensor type 1/4"... -
Page 18: Important Safety Instructions
8. Appendix 8.1 WARNING WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THE MONITOR OR POWER ADAPTER TO WATER OR MOISTURE. CAUTION: DO NOT OPEN. RISK OF ELECTRICAL SHOCK. CAUTION! TO REDUCE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER OR BACK, NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. -
Page 19: Fcc Class B Notice
• Consult the dealer or an experienced radio or television technician 8.4 GENERAL PRODUCT WARRANTY: For all Comelit Branded Products 2 year manufacturer’s warranty from dealer date of Purchase. Proof of purchase by the dealer in the form of an invoice is necessary for all returns. - Page 20 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
