ATOMIC CLOCK WITH OUTDOOR WIRELESS TEMPERATURE
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this state-of-the-art Atomic Clock as an example of superior design
and engineering. Providing WWVB radio-controlled time, date, time zone, indoor and outdoor
temperature display, this innovative clock is ideal for home or office use. Operation of this product is
simple and straightforward. By reading this operating manual, the user will however receive a better
understanding of the Atomic Clock together with the optimum benefit of all its features.
FEATURES:
ATOMIC CLOCK:
LCD1
display
LCD2
display
• WWVB Radio controlled time with manual time setting
• 12/24 hour time display
• Time display: hour, minute, second
• Alarm setting with snooze function
• Calendar display
• Weekday display (3 languages to choose from: English, French and Spanish)
• Time zone setting
• Daylight savings time ON/OFF option (DST)
• ºC or ºF temperature display selectable
WS-8017U
Hanging holes
Function keys
Foldable stand
Battery cover
Foldable stand
• Indoor temperature display
• Outdoor temperature display via 433MHz transmission
• Wall mount or freestanding
OUTDOOR TEMPERATURE TRANSMITTER:
• Remote transmission of outdoor temperature to the Atomic clock by 433 MHz signals
• Wall mounting case
TO INSTALL AND REPLACE BATTERIES IN THE ATOMIC CLOCK
The Atomic Clock uses 2 x AA, 1.5V batteries. To install and replace the batteries, please follow the
steps below:
1.
Insert finger or other solid object in the space at the bottom center of the battery compartment
and lift up to remove the cover.
2.
Insert batteries observing the correct polarity (see marking).
3.
Replace compartment cover.
DO NOT SET THE CLOCK.
TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER
The transmitter uses 2 x AA,1.5V batteries. To install and replace the batteries, please follow the
steps below:
1.
Remove the cover.
2.
Insert the batteries, observing the correct polarity (see marking).
3.
Replace the battery cover on the unit.
Alkaline batteries are recommended for use in both units. Avoid using rechargable batteries.
Holder
Advertisement
Table of Contents
Related Manuals for La Crosse Technology WS-8017U-MAH
Summary of Contents for La Crosse Technology WS-8017U-MAH
-
Page 1: To Install/Replace Batteries
WS-8017U ATOMIC CLOCK WITH OUTDOOR WIRELESS TEMPERATURE Instruction Manual INTRODUCTION: Congratulations on purchasing this state-of-the-art Atomic Clock as an example of superior design and engineering. Providing WWVB radio-controlled time, date, time zone, indoor and outdoor temperature display, this innovative clock is ideal for home or office use. Operation of this product is simple and straightforward. -
Page 2: Manual Settings
SETTING UP: Alkaline batteries are recommended for use in both units. Avoid using rechargable batteries. Do not set the clock until the outdoor temperature is displayed. Place batteries in the outdoor transmitter first, then into the atomic clock. DO NOT PRESS ANY BUTTONS FOR 10 MINUTES. -
Page 3: Language Setting
• Date setting • Weekday setting • 12/24 hour time display setting • ºC or ºF setting TIME ZONE SETTING After entering the manual setting mode as described above, the time zone can be set between the –1 to –12 hour or Greenwich Mean Time (GMT) range in LCD2. To do this: The time zone (LCD2) will start flashing (Default setting "-5h“). -
Page 4: 12/24 Hours Time Display Setting
Press and release the SET key to switch to the “Month Setting”. MONTH SETTING The month digits on LCD2 will start flashing. Set the desired month by use of the + key. Press and release the SET key to move to the mode “Date Setting”. DATE SETTING 1. -
Page 5: Wwvb Radio Controlled Time
3. Using other electrical products such as headphones or speakers operating on the same signal frequency (433MHz) may prevent correct signal transmission and reception. 4. Neighbors using electrical devices operating on the 433MHz signal frequency can also cause interference. Note: When the 433 MHz signal is received correctly, do not re-open the battery cover of either the Outdoor Temperature Transmitter or Atomic Clock, as the batteries may spring free from the contacts and force a false reset. - Page 6 • use of the foldout table stands, or • wall mounting FOLDOUT TABLE STAND The Foldout table stand legs are located on the backside, at the lower corners, and on both sides of the battery cover. The hinges are towards the edges of the Atomic Clock, and the ends (with no hinge) need to be folded out towards the edge.
-
Page 7: Troubleshooting
TROUBLESHOOTING Problem: The LCD is faint. 1) Replace the batteries. Solution: Problem: No reception of WWVB signal Solution: 1) It may help reception to face the front of the Atomic Clock in the general direction of Ft. Collins, Colorado. 2) Wait overnight for signal. 3) Be sure the Atomic Clock is at least 6 feet (2 meters) from any electrical devices, i.e. -
Page 8: Liability Disclaimer
LIABILITY DISCLAIMER: • The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any consequences that occur should an inaccurate reading take place. • This product is only designed for use in the home or office. • This product is not to be used for medical purposes or for public information. •... -
Page 9: Instruction Manual
WS-8017U ATOMIC CLOCK WITH OUTDOOR WIRELESS TEMPERATURE Instruction Manual FCC ID: OMO-01RX (receiver) OMO-01TX (transmitter) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2.
