Installation Instructions
ProSpace™
PTAC Wired Thermostat
Part Number:
THT03191
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
April 2020
SAFETY WARNING
PTAC-SVN030B-EN
Advertisement
Table of Contents
Related Manuals for Trane ProSpace THT03191
Summary of Contents for Trane ProSpace THT03191
- Page 1 Installation Instructions ProSpace™ PTAC Wired Thermostat Part Number: THT03191 SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
-
Page 2: Warnings, Cautions, And Notices
(Global Harmonized System of Classification and compounds have the same potential impact to the Labeling of Chemicals) guidelines for information on environment. Trane advocates the responsible handling of allowable personal exposure levels, proper all refrigerants-including industry replacements for CFCs respiratory protection and handling instructions. - Page 3 Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.
-
Page 4: General Introduction
General Introduction Features • Large LCD back light display. • Adjustable cool/heat settings. • Displays both room temperature and set temperature. • Variable fan speed- high, medium, and low. • Optional cooling, heating, and fan modes. Specifications • Power: 24 +/-10% Vac, 50-60 Hz. •... -
Page 5: Installation
Installation 1. Choose an appropriate location for the wired 3. Mount the wired thermostat base to the wall using the thermostat base. two (2) screws (provided). Use appropriate wall anchors for mounting directly into sheet rock. 2. Remove the wired thermostat display cover. 4. -
Page 6: General Information
Configuration Configuration To enter into configuration mode, press the °F/°C button 3. To set the Maximum Temperature, press MODE and and Mode button simultaneously within 30 seconds after the LCD displays SET POINT and MAX. Press either energizing the wired thermostat. To advance to other can increase/decrease the Maximum configuration modes, press the MODE button. - Page 8 For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
