OPERATION MANUAL
SERIES
MODEL FU162A
HIGH FREQUENCY INVERTER
Revision #0 (05/12/22)
To find the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading

Related Manuals for MULTIQUIP Mikasa Series

Summary of Contents for MULTIQUIP Mikasa Series

  • Page 1 OPERATION MANUAL SERIES MODEL FU162A HIGH FREQUENCY INVERTER Revision #0 (05/12/22) To find the latest revision of this publication or associated parts manual, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — FU162A INVERTER • OPERATION MANUAL — REV. #0 (05/12/22)

  • Page 3: Table Of Contents

    TABLE OF CONTENTS FU162A High-Frequency Inverter Proposition 65 Warning ........... 2 Safety Information ..........4-7 Specifications ............8-9 Dimensions ............10 General Information ..........11 Components ............. 12-13 Inspection .............. 14 Operation ............15-17 Maintenance ............. 18-20 Troubleshooting ..........21-27 NOTICE Specifications and part numbers are subject to change without notice.

  • Page 4: Safety Information

    SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
  • Page 5  NEVER use accessories or attachments that are not  NEVER operate this equipment when not recommended by Multiquip for this equipment. Damage feeling well due to fatigue, illness or when to the equipment and/or injury to user may result.
  • Page 6 SAFETY INFORMATION INVERTER SAFETY ELECTRICAL SAFETY DANGER CAUTION  NEVER operate the equipment in an explosive  Prevent body contact with grounded surfaces such as atmosphere or near combustible materials. An pipes, reinforcing bar, etc. explosion or fi re could result causing severe ...
  • Page 7 SAFETY INFORMATION CAUTION  Ensure that cables and cords will not be tripped over. NOTICE  ALWAYS make certain that proper power or extension cord has been selected for the job.  Use only extension cords that are intended for outdoor use and so marked.

  • Page 8: Specifications

    SPECIFICATIONS Table 1. FU162A Specifications Phase SINGLE PHASE Voltage 100 -120 / 220 - 240 Input Current 20 / 14 Input 2.0 / 2.8 Frequency 50 / 60 Phase THREE PHASE Voltage Current 19.2 Output Input Frequency 100 - 240 Dimensions (L x W x H) 12.8 x 9.5 x 9.8 in (324 x 240 x 248 mm) Total Weight...
  • Page 9 SPECIFICATIONS Table 2. Cord Size Length of Extension Cord (between inverter and vibrator) Size of Power Cord Single phase (100 - 120V) Single phase (220 - 240V) AWG14 46 ft (14 m) 66 ft (20 m) AWG12 82 ft (25 m) 115 ft (35 m) AWG10 125 (38 m)

  • Page 10: Dimensions

    DIMENSIONS Figure 1. FU162A Dimensions Table 4. Dimensions Reference Description Measurement Length 12.8 in (324 mm) Height 9.8 in (248 mm) Width 9.5 in (240 mm) PAGE 10 — FU162A INVERTER • OPERATION MANUAL — REV. #0 (05/12/22)

  • Page 11: General Information

    GENERAL INFORMATION DEFINITION OF INVERTER Commercial power (single-phase AC) enters through the power cable, and when the attached breaker switch is The Mikasa FU162A with built-in high frequency induction turned on, electric current flows through the circuit. This motor, is a special inverter to convert single phase AC 80- current is converted to direct current via the rectifier and 130V and single phase AC180-250V power to the voltage the condenser.

  • Page 12: Components

    COMPONENTS Connector Standard: NEMA 5-20P Maximum Voltage: 250V Maximum Current Rating: 20A Figure 2. FU162A Controls and Components PAGE 12 — FU162A INVERTER • OPERATION MANUAL — REV. #0 (05/12/22)
  • Page 13 COMPONENTS Figure 2 shows the location of the basic controls and 6. Frequency Adjustment /Abnormality Display Switch — The display indicates operation frequency, components of the FU162A Inverter. The function of each control is described below: input voltage, output current, input current in normal mode.

  • Page 14: Inspection

    INSPECTION BEFORE STARTING 1. Read safety instructions at the beginning of manual. 2. Check power plug and contact for dirt, rust, deformation and breakage. 3. Check power cable for wear, crushing, crack, etc. 4. Open the output outlet cover to check inside and terminal part for dirt, etc.

  • Page 15: Operation

    OPERATION 1. Check to see if the power source matches the 3. Turn on the inverter circuit protector switch (Figure 3). specification of this inverter and the voltage is within Make sure that the cooling fan starts and the green LED the normal voltage range of this product.
  • Page 16 OPERATION 6. Make sure that the switch of the work machine CAUTION (vibrator), is turned off. When using FX Series of high frequency vibrators, 7. Insert the male plug of the work machine securely into always use the frequency of 240 Hz. Do not set to the the end of the inverter output outlet (Figure 6).
  • Page 17 OPERATION ABNORMALITY INDICATION DISPLAY FUNCTION abnormality might have occurred in the power source or in the machine. Correct the cause of the trouble After the inverter circuit protector switch is turned on and before resuming work. an error occurs, error code is displayed on the Frequency 12.

  • Page 18: Maintenance

    MAINTENANCE Check the following items before and after use. 3. Check the output side outlet cover to make sure it closes. if it does not close properly, water might enter 1. Check power plug and contact for dirt, rust, deformation inside through the terminal part.
  • Page 19 MAINTENANCE INPUT POWER VOLTAGE CONDITION/ Table 8. Abnormality Indication Display Function ABNORMALITY INDICATION FUNCTION Input power voltage condition display function Description of Error Abnormal Display Display Condition Status The FU162A inverter has three-color high-intensity LED (lighting) FU162A lamps on the panel outlet side of the main unit, to display input power voltage condition and inverter abnormality in Input voltage drop four different modes.
  • Page 20 MAINTENANCE Table 9. Error Countermeasures Inverter restart Error Description LED Status Machine Behavior Countermeasure method and (LED Display) required action Power source E01 Blinking Input low voltage Red light ON Output stop inspection/ Inspection/replacement replacement E02 Lights up Red light ON and Inverter stop and Power source Circuit protector...

  • Page 21: Troubleshooting

    TROUBLESHOOTING Troubleshooting (Frequency Inverter) Symptom Possible Problem Solution Input plug is not connected to the Connect to the power source that matches power source? the rating of the machine. Main power is cut. (Main breaker is The Inverter Does Not Run Turn on the main power [main breaker ON].
  • Page 22 TROUBLESHOOTING Troubleshooting (Frequency Inverter) Circuit protector switch is not ON? Circuit protector switch ON. Immediately stop using, inspect the wiring and control substrate, replace the circuit The Inverter Does Not Run Circuit protector switch is not protector switch assembly (depending on Even When The Circuit functioning? the condition of breakage, the substrate...
  • Page 23 TROUBLESHOOTING Troubleshooting (Frequency Inverter) Never turn on the power. Danger of electric Immersion in water due to mud fl ow, Water (liquid) and dust gets in shock and electric leakage. With the power mud water and dirty water by natural the machine.
  • Page 24 TROUBLESHOOTING Troubleshooting (Frequency Inverter) Cooling fan rotation part was broken, damaged or deformed because of the foreign matter entered into the cooling fan rotation part or because the machine was dropped or a strong impact was applied to it, which Cooling Fan Trouble results in rotation lock and abnormal (Power is on, external cooling...
  • Page 25 TROUBLESHOOTING Troubleshooting (Frequency Inverter) Stop your work, and after checking the power source voltage, lower the voltage of replace the power source. (Red LED Input power high voltage? lamp turns ON then goes out immediately. Machine Operation Trouble Abnormality description [error code: E02] (power is on but machine does is saved.
  • Page 26 TROUBLESHOOTING Troubleshooting (Frequency Inverter) Check the power source voltage and the area of electric leakage, and also do inspection and check of the equipment and Main power is cut (Circuit protector machine using the same power source. If switch is turned OFF)? there is no problem, turn on the main power.
  • Page 27 TROUBLESHOOTING Troubleshooting (Frequency Inverter) After making sure the switch of this machine Operation Frequency (LED Power plug is not connected to the is turned OFF, connect to the power source. Display) Is Not Shown (no power source? Then check the display. (If the switch is ON, power) turn it OFF.) Relay power connector on frequency...
  • Page 28 © COPYRIGHT 2022, MULTIQUIP INC. Multiquip Inc , the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
