April 22, 2003
Alarms
HDSL ES 15 MIN
HDSL ES 24 HOUR
HDSL UAS 15 MIN
HDSL UAS 24 HR
HDSL LOW MARGIN
ADC Telecommunications, Inc.

Table 16. HDSL Alarm Thresholds

Value
0 to 900 HDSL ES 15 minutes alarm is generated if the
current 15-minute HDSL ES count reaches or
exceeds this threshold
0 to 65,000 HDSL ES 24 hour alarm is generated if ES 24
hour counts become equal to or greater than this
threshold
0 to 900 HDSL UAS-15 minutes alarm is generated in the
current 15-minute HDSL UAS count reaches or
exceeds this threshold
0 to 65,000 HDSL UAS-24 hour alarm is generated if UAS
counts become equal to or greater than this
threshold
0 to 15 HDSL Low Margin alarm is generated if margin
drops equal to or less than this threshold
SCP-FLL814-012-04H
Description Default
17
170
240
600
6
77
