Appendix 1

Technical Data

Print Technique
Print Resolution
Quick-mount Printhead
Maximum Print Width
Maximum Media Width
Smooth Fonts
Print Directions
Maximum Internal Media Roll Diameter
Maximum Ribbon Length
Dimensions (W x D x H)
Weight (excluding media, ribbon, & options) 4.7 kgs (10.3 pounds)
Ambient Operating Temperature
Humidity
Sound Emission Level
Microprocessor
Firmware
Label and Ribbon End Sensors
Mains Voltage
PFC Regulation
Maximum Power Consumption
Communications Interface Standard
Print Speed (tear-off)
Print Speed (peel-off/roll Ø 152 mm)
Print Speed (LTS enabled)
Bar Code Generators
On-board Flash EPROMs
On-Board RAM Memory
RS-232 Cable
Centronics Parallel Cable
Real Time Clock (RTC)
Label Taken Sensor
Scaleable Fonts
Memory Card Slot
Paper Cutter
Bar Code Wand
44
Direct Thermal/Thermal Transfer
8 dots/mm (203.2 dots/inch)
Yes
104 mm (4.09 inches)
114 mm (4.5 inches)
Yes
4
152 mm (6 inches)
~200 metres (656 feet)
236 x 350 x 170 mm (9.3 x 13.78 x 6.7 inches)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
< 60 dB (A)
32 bit
Intermec EasyCoder E4 Direct Protocol 2.01
Yes
110 to 120/220 to 240 VAC, 4/2A, 60/50Hz
IEC 61000-3-2
Stand-by 30W; Typical label 70W; Maximum 250W
1 x RS-232 Serial and 1 x Centronics Parallel
100 or 150 mm/sec (4 or 6 inches/sec)
100 mm/sec. (4 inches/sec)
100 mm/sec. (4 inches/sec)
38
2 x 512K
512K
Optional
Standard
Optional
Fitted
Built-in
1 PCMCIA 5V Type 3, or 2 PCMCIA 5V Type 1 or 2
Optional
Optional
Intermec EasyCoder E4 – Installation & Operation Ed. 2
Build option
Recommended
