Operation Media Load - Tear-Off (Straight-Through); Media Load – Tear-Off (Straight-Through) - Intermec EasyCoder E4 Installation And Operation Manual

Operation
Media Load –
Tear-Off
(Straight-through)
1
1
Open the side and front covers.
Intermec EasyCoder E4 – Installation & Operation Ed. 2
The same loading principles apply to thermal transfer receiving
media as well as direct thermal media. Linerless media requires an
EasyCoder E4 LinerLess printer.
To tear off the media after feeding or printing it, pull it downwards
against the tear bar.
Before shipping the printer, always remove any roll from the
media supply roll post.
HINT!
To facilitate media and ribbon load, you can remove the side cover
by opening it halfway (45°) and lift the hinges out of their pockets
in the bottom moulding.
2
Caution!
2
Raise the printhead.
Chapter 3
11
