- Page 1 Owner’s Manual PRECAUTIONS pages 4 to 6 Quick Start Guide pages 9 to 11 Troubleshooting pages 18 to 20...
- Page 2 TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT normalement ou est tombé. EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. (UL60065_03) AVERTISSEMENT POUR RÉDUIRE LES RISQUES D’INCENDIE OU DE DÉCHARGE ÉLECTRIQUE, N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. (UL60065_03) MG12XUK Owner’s Manual...
- Page 3 “ON” , please try to eliminate the problem by using one of contained in this manual, meets FCC requirements. Modifica- the following measures: tions not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. Relocate either this product or the device that is being affected by the interference.
-
Page 4: Precautions
If some trouble or device inspected by qualified Yamaha service personnel. malfunction occurs, immediately turn off the power switch and disconnect the plug from the outlet. Even when the... - Page 5 • This product incorporates and bundles computer programs and contents in which Steinberg Media Technologies GmbH and Yamaha Corporation own copyrights or with respect to which it has license to use others' copyrights. Such copyrighted materials include, without limitation, all computer software, style files, MIDI files, WAVE data, musical scores and sound recordings.
- Page 6 VAROITUS: Laitteen toisiopiiriin kytketty käyttökytkin ei irroita koko lait- etta verkosta. (standby) 이 기기는 가정용 (B 급 ) 전자파적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며 , 모든 지역에서 사용할 수 있습니다 . (class b korea) MG12XUK Owner’s Manual...
-
Page 7: Table Of Contents
Thank you and congratulations on your purchase of the Yamaha MG12XUK mixing console. This product is a mixing console for adjusting the balance of multiple sound sources. This manual explains, for users who may not be familiar with mixers, how to mix multiple sound sources during live performances by a band or in other events. -
Page 8: Main Features
24 High-Quality Digital Effects MG12XUK features 24 built-in effects that are based on SPX algorithms used by professionals. In particular, the high- quality reverb and delay expand the spatial quality of the sound with remarkable realism and naturalness. 24-bit/192 kHz USB Audio Interface MG12XUK features a USB 2.0 audio interface capable of 24-bit/192 kHz sound quality. -
Page 9: Quick Start Guide
Make sure that all devices to be connected to the unit are turned off. Connect speakers, microphones and instruments referring to the connection example below. Connection Example Rear Panel Powered speaker Powered monitor speaker Electric acoustic guitar Microphones Computer Electric keyboard Footswitch (Yamaha FC5) Top Panel Headphones Portable audio player MG12XUK Owner’s Manual... -
Page 10: Step 2 Getting Sound To The Speakers
Turn all the level control knobs fully to the left (min- imum). These include the [GAIN] knobs (white), Make sure that the volume of a powered speaker or [LEVEL] knobs (white), and [STEREO LEVEL] knob amplifier is set to the minimum. (red). MG12XUK Owner’s Manual... - Page 11 If the sound is not heard or the sound is distorted, follow the instructions on page 18. Set the [LEVEL] knobs as necessary to adjust the volume balance between the corresponding chan- nels. This completes the STEP 2 instructions. MG12XUK Owner’s Manual...
-
Page 12: Controls And Functions
If you hear distortion or the [PEAK] LED !0 lights, turn the switch on ( NOTE Turn the [LEVEL] knob to "0" (minimum) before toggling the [PAD] switch on ( ) and off ( ). Otherwise, noise may be produced. MG12XUK Owner’s Manual... - Page 13 When the knob is located at the 12 o’clock position, the channel’s sound will be sent to the stereo bus channels (L and R) at the same volume. In this case, the sound image is positioned at the center. MG12XUK Owner’s Manual...
-
Page 14: Master Section
[FX] knob respectively. !6 [STEREO OUT] jacks For connecting a powered speaker or amplifier. These jacks support both XLR and phone plugs. !7 [PHONES] output jack For connecting a set of headphones. This jack supports a stereo phone plug. MG12XUK Owner’s Manual... -
Page 15: Internal Effect Section
Adjusts the volume of the internal effect sound. u [FOOT SW] jack For connecting an optionally available unlatched type footswitch, such as the Yamaha FC5. When the [FX ON] switch t is turned on ( ), the internal effects can be toggled on/off with the footswitch as needed with your foot. -
Page 16: Rear Panel
For inputs and outputs to/from the computer, you may need a dedicated USB driver. Check and download the driver at the following Yamaha web site and install it to the computer before use. The cable should be no more than 3 meters long. -
Page 17: Applying Effects
Applying Effects The MG12XUK features high-quality built-in signal processing effects that are in the same league as our famed SPX effect processor series. Applying effects (as described below) allows you to simulate the acoustics of different perfor- mance environments. Effect Programs... -
Page 18: Troubleshooting
Signal is input from a micro- [PHONES] jack phone or instrument. Adjust tone and level for each channel. Make final adjustments to the level of the signal. Route signals from channels to the master block. MG12XUK Owner’s Manual... - Page 19 [MONITOR/PHONES] knob For adjusting the headphone [PEAK] level and the MONITOR level. indicators [LEVEL] knobs [STEREO LEVEL] knob For adjusting the level for each For adjusting the overall volume, channel. with “” as the nominal level. MG12XUK Owner’s Manual...
-
Page 20: Other
Use the [COMP] knob to lower the level. The volume of audio play-back Use the “Attenuator Function” . For details, see page 16. from a computer need to be adjusted. If any specific problem should persist, please contact your Yamaha dealer. MG12XUK Owner’s Manual... -
Page 21: Technical Specifications
Phantom Power Voltage +48 V PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) Power Supply adaptor or equivalent recommended by Yamaha Power Consumption 22.9 W Dimensions (W×H×D) 315 mm × 91 mm × 297 mm (12.4” × 3.6” × 11.7”) Net Weight 3.0 kg (6.62 lbs) -
Page 22: Analog Input Characteristics
44.1 kHz, 48 kHz, 88.2 kHz, USB Audio Class 2.0 16 /24 bit USB Standard-B 96 kHz, 176.4 kHz, 192 kHz *1 Data length is depend on the using audio format. USB Audio Class2.0: 16 / 24-bit, Yamaha Steinberg USB Driver: 24-bit MG12XUK Owner’s Manual... -
Page 23: Jack And Connector List
White This type of unbalanced connector is most commonly found on home audio and video equipment. RCA type pin jacks are often color coded: white for left audio channel and red for right audio channel, for example. MG12XUK Owner’s Manual... -
Page 24: Block And Level Diagrams
Technical Specifications Block and Level Diagrams MG12XUK Owner’s Manual... -
Page 25: Dimensions
Technical Specifications Dimensions Unit: mm * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. MG12XUK Owner’s Manual... - Page 26 MG12XUK Owner’s Manual...
- Page 28 Yamaha Pro Audio global website: http://www.yamaha.com/proaudio/ Yamaha Downloads: http://download.yamaha.com/ Manual Development Group © 2018 Yamaha Corporation Published 01/2018 POEM-A0 ZY29460...
