MODEL 463248708 • PRODUCT GUIDE
THIS GRILL IS FOR OUTDOOR USE ONLY.
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
1-888-430-7870
.
463248708 • 80016375 • 03-27-08
Advertisement
Table of Contents
Related Manuals for Char-Broil COMMERICAL 463248708
Summary of Contents for Char-Broil COMMERICAL 463248708
- Page 1 MODEL 463248708 • PRODUCT GUIDE THIS GRILL IS FOR OUTDOOR USE ONLY. CAUTION: Read and follow all safety statements, assembly instructions, and use and care directions before attempting to assemble and cook. INSTALLER/ASSEMBLER: Leave this manual with consumer. CONSUMER: Keep this manual for future reference. If you have questions or need assistance during assembly, please call To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com WARNING:...
-
Page 2: For Your Safety
DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. WARNING 1. -
Page 3: Table Of Contents
TABLE OF CONTENTS For Your Safety ........2 Grill Service Center. -
Page 4: Use And Care
USE AND CARE DANGER • NEVER store a spare LP cylinder under or near the appliance or in an enclosed area. • Never fill a cylinder beyond 80% full. • An over filled or improperly stored cylinder is a hazard due to possible gas release from the safety relief valve. -
Page 5: Connecting Regulator To Lp Cylinder
LP Cylinder Exchange • Many retailers that sell grills offer you the option of replacing your empty LP cylinder through an exchange service. Use only those reputable exchange companies that inspect, precision fill, test and certify their cylinders. Exchange your cylinder only for an OPD safety feature-equipped cylinder as described in the "LP Cylinder"... - Page 6 Hold coupling nut and regulator as shown for proper connection to LP cylinder valve. 6. Turn the coupling nut clockwise and tighten to a full stop. The regulator will seal on the back-check feature in the LP cylinder valve, resulting in some resistance. An additional one-half to three-quarters turn is required to complete the connection.
- Page 7 WARNING For Safe Use of Your Grill and to Avoid Serious Injury: • Do not let children operate or play near grill. • Keep grill area clear and free from materials that burn. • Do not block holes in sides or back of grill. •...
- Page 8 WARNING Turn controls and gas source or tank OFF when not in use. CAUTION If ignition does NOT occur in 5 seconds, turn the burner controls OFF, wait 5 minutes and repeat the lighting procedure. If the burner does not ignite with the valve open, gas will continue to flow out of the burner and could accidently ignite with risk of injury.
-
Page 9: Spider Alert
CAUTION SPIDER ALERT! SPIDER AND WEBS INSIDE BURNER TUBE If you notice that your grill is getting hard to light or that the flame isn’t as strong as it should be, take the time to check and clean the venturi’s. VALVE CONTROL PANEL In some areas of the country, spiders or small insects have been... - Page 10 Food Safety Food safety is a very important part of enjoying the outdoor cooking experience. To keep food safe from harmful bacteria, follow these four basic steps: Clean: Wash hands, utensils, and surfaces with hot soapy water before and after handling raw meat and poultry. Separate: Separate raw meats and poultry from ready-to-eat foods to avoid cross contamination.
- Page 11 The methods below are suggestions for cleaning stainless steel surfaces. Choose a cleaning method appropriate for your needs. It is recommended that you use a Char-Broil® grill cover to help prolong the life and prevent discoloration of your grill.
-
Page 12: Parts List
PARTS LIST – Model No. 463248708 Key Qty Description Bottom Shelf..... 80016961 Locking Caster ....80000268 Fixed Caster. -
Page 13: Parts Diagram
PARTS DIAGRAM – Model No. 463248708 463248708 • 13... -
Page 14: Assembly
ASSEMBLY – Model No. 463248708 Attach the two locking casters at the rear of the bottom shelf and the two fixed casters at the front. Use the provided caster wrench to fully tighten casters. Locking caster Bottom shelf Attach side panels to bottom shelf using three 1/4-20x1/2” screws, 7mm lock washers, and 7mm flat washers per panel shown A. - Page 15 Place lower back panel between side panels at rear of bottom shelf. Make sure the slots are positioned as shown (A). Secure lower back panel to side panels using two 1/4-20x1/2” screws, 7mm lock washers, and 7mm flat washers on each side. Upside Left Downside...
- Page 16 Insert front brace under control panel and between cart side panels with door magnets towards the top. Secure using four 1/4-20x1½” screws, 7mm lock washers, and 7mm flat washers, two on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
- Page 17 Insert tabs on right side shelf into rectangular slots in side of side panel. Attach rear of shelf using one 1/4-20x3/4” screw, 7mm lock washer, and 7mm flat washer in upper hole. Use one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer in lower hole.
- Page 18 Insert tabs on left sideburner shelf assembly into rectangular slots in side of side pane show (A). Attach rear of shelf using one 1/4-20x3/4” screw, 7mm lock washer, and 7mm flat washer in upper hole. Use one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer in lower hole.
- Page 19 First, remove the two screws and lock washers factory attached to the sideburner valve bracket. Position sideburner valve bracket beneath sideburner shelf fascia so that valve stem comes through larger center hole in fascia. Align the holes on valve bracket with left and right holes on fascia. Secure using lock washers and screws that were removed from bracket. Next, place sideburner bezel over valve stem on front side of fascia.
- Page 20 Place sideburner lid onto left shelf and align holes in back of lid with hinge holes. Secure lid to hinges using four #10-24x3/8” screws, 5mm flat washers, 5mm lock washers, and #10-24 hex nuts. NOTE: Fully secure one hinge with screws, washers and nuts, then secure remaining hinge.
- Page 21 Inside of cart, insert tank heat shield tabs into two left slots between upper and lower back panels. Attach left and center front shield tabs under door brace with #8x3/8” self-tapping screws. Insert left and right grease tray rails into slots beneath grease tray opening in upper back panel.
- Page 22 Attach both doors using eight #8-32x3/8” flat head screws and two #4.2x10 self tapping screw. Wiring Connections Connect each of the wires from the main burner electrodes, and sideburner electrode into the back of the Electronic Ignition Module. Total (6) connections. Connect the two wires(A and B) from the switch wiring harness into the back of the Electronic Ignition Module.
- Page 23 Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox. Place the four cooking grates onto the firebox. Insert the four wire ends at rear of warming rack into holes in back of firebox. Front wires of warming rack rest on sides of firebox.
- Page 24 LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Care section). Once cylinder has been filled and leak checked, place cylinder into hole in bottom shelf. Make sure cylinder valve is facing front of grill.
-
Page 25: Troubleshooting
EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Gas leaking from • Damaged hose. cracked/cut/burned hose. Gas leaking from LP • Mechanical failure due to rusting or cylinder. - Page 26 Troubleshooting (continued) Problem Possible Cause ELECTRONIC IGNITION: Burner(s) will not light using ignitor. • No spark, no ignition noise. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • Sparks, but not at electrode or at full strength. PIEZO PUSH-BUTTON AND ROTARY: •...
- Page 27 Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™...
-
Page 28: Limited Warranty
Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-888-430-7870 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above. 28 • 463248708 Char-Broil Consumer Relations P. O. Box 1240 Columbus, GA 31902-1240... -
Page 29: Registration Card
¿Qué producto está registrando? Quel produit enregistrez-vous? Gas Grill/Parrilla a gas/Gril au gaz Electric Grill/Parrilla eléctrica/Gril électrique Smoker/Ahumador/Fumoir Charcoal Grill/Parrilla a carbón/Barbecue au charbon Charcoal Smoker/Ahumador a carbón/Fumoir au charbon Outdoor Fireplace/Chimenea para exteriores/Foyer extérieur Cooker/Fryer / Cocina/freidora / Cuiseur/Friteuse Other/Otro/Autre Thank you for completing this questionnaire. - Page 30 This page intentionally blank 30 • 463248708...
- Page 31 This page intentionally blank 463248708 • 31...
- Page 32 Always ensure control knobs are in OFF position and regulator is attached to tank BEFORE opening tank valve to avoid low flames. Perform leak test regularly. Thank You for Your Purchase! Char-Broil, LLC • Columbus, GA 31902 • Printed in China...
