- Page 1 WARRANTY PART REPLACEMENT GUIDE MODEL | MODELO 463246018 463246118 MODULAR OUTDOOR KITCHEN 80029739 • 05/24/19...
- Page 2 Each step shows removal and replacement of parts. Follow the steps in order to remove parts, then reverse the steps to replace all parts. Remove and replace WARMING RACK. WARMING RACK Remove and replace COOKING GRATES. COOKING GRATE PAGE 2...
- Page 3 Remove and replace IR GRATES. IR GRATE Remove and replace HEAT TENTS. HEAT TENT PAGE 3...
- Page 4 Remove and replace CARRY OVER TUBES and PORT CAPS. HITCH PINS CARRY OVER TUBE PORT CAP PAGE 4...
- Page 5 Unplug and replug ELECTRODE WIRES and LIGHT WIRE. • Unplug/ replug ELECTRODE WIRES. • Unplug/ replug LIGHT WIRE. • Remove/ replace Tie Wrap to unbundle/ bundle ELECTRODE WIRES. • Remove/ replace LIGHT WIRE from rear of TOP SHELF. REAR OF GRILL TIE WRAP LIGHT WIRE ELECTRODE WIRE...
-
Page 6: Firebox Assembly
Remove and replace TOP LID ASSEMBLY. TOP LID ASSEMBLY Remove and replace FIREBOX ASSEMBLY. FIREBOX ASSEMBLY PAGE 6... -
Page 7: Heat Shield
Remove and replace HEAT SHIELD. HEAT SHIELD Remove and replace GREASE BOX. GREASE BOX PAGE 7... -
Page 8: Tank Heat Shield
Remove and replace TANK HEAT SHIELD. TANK HEAT SHIELD TANK HEAT SHIELD PAGE 8... - Page 9 Remove and replace DRAWERS. DRAWER Left rail of drawer Right rail of drawer NOTE: press the clips on left and right rails as the arrows indicate to remove drawers. PAGE 9...
- Page 10 Remove and replace SHELF FRAME. SHELF FRAME Remove and replace DRAWER RAIN SHIELD. DRAWER RAIN SHIELD REVERSE THE STEPS TO ASSEMBLE THE GRILL. NOTE: READ THE USE AND CARE GUIDE IN INSTRUCTION MANUAL PRIOR TO LIGHTING THE GRILL.
