4-16 C M
ONFIGURING THE
Monitoring the
Front Panel
ODULE
The LEDs on the front panel of the media module allow you to monitor
the status of each port. Each media module has a Status LED for each
port. Figure 4-2 shows the location of the LEDs. Each LED indicates the
state of a port as described in
1
4
7
10
13
16
Active Per-Port Active Per-Module
Switching Module Switching Module
Figure 4-2

Media Module Faceplates

Table 4-3.
1 3
4 6
9
7
12
10
13 15
16
18
Passive Media
Module
MODULE
STATUS
1 2
3 4
5 6
7 8
9 10
RO1
RI1
RO2
RI2
JA1 JA2
Dual Fiber
Repeater Module
