INTELLIFLO3™ VSF
INTELLIPRO3™ VSF
VARIABLE SPEED AND FLOW PUMPS
INSTALLATION AND
MAINTENANCE GUIDE
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Digital copies of all IntelliFlo3 VSF manuals,
as well as translated versions, can be found
at www.pentair.com, or by scanning the
provided QR code.
• Install and Maintenance Guide (P/N 356231)
• User's Guide (P/N 356088)
Se pueden encontrar copias digitales de
todos los manuales de IntelliFlo3 VSF,
así como versiones traducidas en www.
pentair.com, o escaneando el código QR
proporcionado.
• Guía de instalación y servicio (P/N 357973)
• Guía del usuario (P/N 357971)
Des copies numériques de tous les manuels
IntellFlo3 VSF, ainsi que les versions traduites,
peuvent être trouvées sur www.pentair.com, ou
en scannant le code QR fourni.
• Guide d'installation et d'entretien (P/N 357974)
• Guide d'utilisation (P/N 357972)
Advertisement
Table of Contents
Related Manuals for Pentair STA-RITE INTELLIFLO3 VSF
Summary of Contents for Pentair STA-RITE INTELLIFLO3 VSF
- Page 1 IntelliFlo3 VSF, IntellFlo3 VSF, ainsi que les versions traduites, at www.pentair.com, or by scanning the así como versiones traducidas en www. peuvent être trouvées sur www.pentair.com, ou provided QR code.
-
Page 2: Important Safety Instructions
This guide provides installation and operation instructions for this pump. • The pump is not submersible. Consult Pentair with any questions regarding this equipment. • The pump is capable of high flow rates; use caution when installing and Attention Installer: This guide contains important information about the programming to limit pumps performance potential with old or questionable installation, operation and safe use of this product. - Page 3 IMPORTANT SAFETY INSTRUCTIONS TO MINIMIZE THE RISK OF INJURY DUE TO HAZARDOUS PRESSURE: STAND CLEAR OF PUMP SUCTION ENTRAPMENT HAZARD: AND FILTER DURING START UP. Circulation systems operate under high pressure. When • A properly installed and secured ANSI/ASME A112.19.8 approved anti- any part of the circulating system (i.e.
-
Page 4: Table Of Contents
Relay Control Board Digital Inputs TECHNICAL DATA ..........OPERATION ............1.5 HP Pumps Drive Controls/Buttons Technical Specifications Priming the Pump Pump Dimensions Pentair Home Operation Pump Performance Curves Touchscreen Operation 3 HP Pumps Pump Dashboard Technical Specifications Program Setup Pump Dimensions... -
Page 5: Overview
• WiFi and Bluetooth Wireless Technology ® Connectivity Available Accessories • Pentair Home App Compatibility • Drive-mounted Touchscreen Controller • Flow based programming for precise and (P/N 356159z - Almond, P/N 356348z - Black) continuous control of pump output • Relay Control Board Kit (P/N 356365z) •... -
Page 6: Installation
INSTALLATION Only a qualified plumbing professional should install the pump. Refer to “Important Safety Instructions” 3 IN. (7.6 CM) on pages i - ii for additional installation and safety MINIMUM information. Note: The pump should not be connected in series with other pumps. -
Page 7: Electrical Installation
3. The pump should be permanently connected to its own MAIN POWER independent GFCI-protected circuit. TERMINAL Note: Pentair offers 2-Pole 20 Amp GFCI breakers (P/N PA220GF) which offer personnel protection GROUND SCREW while meeting 2008 to current NEC Standards for (GREEN) Pool Pumps. -
Page 8: Connecting To An Automation System
• Touchscreen Controller (if installed) will display a message indicating the pump is being controlled by an automation system • Pentair Home app will display a message confirming the pump is being controlled by an automation system • All pump control is handled by the automation system •... -
Page 9: Relay Control Board Digital Inputs
This digital input program will override any scheduled programs, automation or manual input. Note: Refer to the Pentair Home User's Guide (P/N 356088) for instructions on viewing and editing the pump programs. Note: Refer to the Relay Control Board Installation Guide (P/N 356994) for instructions on installing the control board. -
Page 10: Operation
LED behaviors. 2. Close all valves in suction and return lines. CONNECT: Press to connect the pump to the Pentair Home app. Refer to the Pentair Home User's Guide 3. Open the filter's air relief valve and relieve all pressure from the filtration system. -
Page 11: Pentair Home Operation
The Pentair Home app allows you to program and operate the pump from your smartphone. For instructions on how to create an app account and operate your pump via the Pentair Home app, refer to the Pentair Home User's Guide (P/N 356088) provided with your pump. -
Page 12: Program Setup
Program Setup Pump Dashboard ˃ All Programs > Program "PUMP DASHBOARD" SCREEN Setup Programs can be individually set and edited from the All Programs screen, accessed from the Pump Dashboard. PUMP DASHBOARD SCREEN 1− See Running Programs: View and edit all enabled pump programs. -
Page 13: Device Settings
Device Settings Pump Dashboard ˃ Device Settings Device Settings can be accessed by pressing the Device Settings gear icon ( ) in the bottom-right of the Pump Dashboard. Tap EDIT to enter any of the menus described below: 1− Product Overview: View general information about your pump such as device nickname, address or software version. -
Page 14: Relay Settings
Relay Settings "RELAYS" SCREEN Pump Dashboard ˃ Device Settings ˃ Relays The following functionality is only available if the Pentair Relay Control Board (P/N 356365z -- sold separately) has been installed on your pump. The relay board includes two high-voltage terminals... -
Page 15: Limits Parameters
Limits Parameters Pump Dashboard ˃ Device Settings ˃ Limits Parameters Set and edit pump speed, flow and pressure limits. These settings will ensure your pump does not operate outside of the programmed parameters. Tap EDIT to view and edit the following speed, flow and pressure limits: 1- Minimum/Maximum Speed: Set the absolute minimum and maximum speeds the pump will be... -
Page 16: Touchscreen Menu Tree
Touchscreen Menu Tree DASHBOARD ALERTS (pg. 7) SEE RUNNING RUNNING PROGRAMS PROGRAMS FAVORITE PROGRAM SETUP FAVORITES NICKNAME PROGRAMS (pg. 8) PROGRAMS ALL PROGRAMS SELECT MODE MANUAL TIMER SCHEDULE DAYS (Schedule ONLY) START - END TIME (Schedule ONLY) TIMER (Timer ONLY) SET SPEED / FLOW SET RELAY DEVICES DEVICE SETTINGS... -
Page 17: Maintenance
MAINTENANCE Always disconnect power to the pump at the circuit breaker and relieve pressure in the filtration system before servicing the pump. Failure to do so could result in death or serious injury to serviceman, pool users or others due to electric shock. Do NOT attempt to adjust or service without consulting your dealer or a qualified pool technician. -
Page 18: Servicing
SERVICING Always disconnect power to the pump at the circuit breaker before servicing the pump. Failure to do so could result in death or serious injury to serviceman, pool users or others due to electric shock. Do NOT attempt to adjust or service without consulting your dealer or a qualified pool technician. - Page 19 [ PAGE LEFT BLANK ] INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide...
-
Page 20: Disassembly
Disassembly Reassembly 1. If installing a new Shaft Seal: TOOLS REQUIRED: • Socket Wrench and 9/16" Socket Scratching, marring or otherwise damaging the polished • 1/4-inch Hex-head Wrench shaft seal faces will cause the seal to leak. Always • No. 2 Phillips-head Screwdriver handle the shaft seal faces with care and clean them thoroughly before reassembling the pump. -
Page 21: Disassembly/Reassembly Diagram
Pump Disassembly/Reassembly Diagram INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide... -
Page 22: Drive Removal And Installation
Drive Removal and Installation To avoid dangerous or fatal electrical shock hazard, switch OFF power to motor before working on pump or motor. FIRE AND BURN HAZARD. The pump motor may run at high temperatures. To reduce the risk of fire, do NOT allow leaves, debris, or foreign matter to collect around the pump motor. -
Page 23: Troubleshooting
Bluetooth ® Bluetooth ® Restart the Pentair Home app. Adjust the pump antenna. Ensure smartphone permissions are given to the pump. - Troubleshooting Continues on the Next Page - INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide... - Page 24 • If using a touchscreen controller, refer to Priming Parameters on page 10 for instructions. • If using the Pentair Home app, refer to the Pentair Home User's Guide (P/N 356088) for instructions. Priming alerts Refer to Alarms and Warnings on page 22 for information regarding specific alarms.
- Page 25 Troubleshooting Chart (continued) PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Pump is Noisy or Debris in contact with cooling fan Ensure the fan guard is clean. Use compressed air to Operating Loudly. remove any dirt, debris or blockages. Clogged impeller Disassemble the pump and remove debris from the impeller.
-
Page 26: Alarms And Warnings
The motor and drive are not able to reduce speed enough to protect themselves. Exceeded & Cut to prevent the drive from The motor will stop and Pentair Home will display this alarm. overheating. When the drive has cooled enough, it will automatically resume operation and attempt to run the requested program. -
Page 27: Maintenance Log
Maintenance Log INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide... -
Page 28: Replacement Parts
REPLACEMENT PARTS INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide... -
Page 29: Parts List (1.5 Hp Models)
Pump Parts List (3 HP Models) Pump Parts List (1.5 HP Models) Almond Black Almond Black Item Description Item Description Part # Part # Part # Part # Drive Cover Assembly 356214z 356349z Drive Cover Assembly 356214z 356349z Field Wiring Compartment Kit 356096Z 356337z Field Wiring Compartment Kit... -
Page 30: Technical Data
TECHNICAL DATA Technical Specifications (1.5 HP Models) Input Voltage Nominal Environmental 115/208-230 VAC NEMA Type 3 / IPX5 Enclosure Rating Input Current 12.0/6.4-5.9 Amps Ambient Condition Range Input Frequency 1PH, L1-L2 or L-N, 50 or 60 Hz Storage -40°C to +60°C (-40°F to 140°F) Max Input Watts 1350 W Operating... -
Page 31: Hp Pumps
Technical Specifications (3 HP Models) Input Voltage Nominal 208-230 VAC Environmental NEMA Type 3 / IPX5 Enclosure Rating Input Current 12.4/11.2 Amps Ambient Condition Range Input Frequency 1PH, L1-L2 or L-N, 50 or 60 Hz Storage -40°C to +60°C (-40°F to 140°F) Max Input Watts 2590 W Operating... - Page 32 WWW.PENTAIR.COM All indicated Pentair trademarks and logos are property of Pentair. Third party registered and unregistered trademarks and logos are the property of their respective owners. The Bluetooth® word mark and logo are registered trademarks of Bluetooth SIG, Inc. in the United States and/or other countries.
