Summary of Contents for Sirius Satellite Radio Valentina SLT977EMEL
- Page 1 Congratulations on your purchase! Thank you for choosing a Sirius product. User manual for ‘The Kite’ and ‘The Line’ Rangehoods INSTALLATION AND USE INSTRUCTIONS ‘The Kite’ SLT977EMEL EAN #9351116003050 ‘The Line’ SLT978EMELBK EAN #9351116001353...
-
Page 3: Table Of Contents
BEFORE YOU INSTALL TO THE ATTENTION OF THE USER PRE-INSTALLATION CHECKS BEFORE YOU INSTALL ATTACHING THE PENDANT LIGHT LINE MEASUREMENTS INSTALLING THE TIMBER SUPPORT BEAMS MOTOR AND VENTING OPTIONS TOP VENT INSTALLATION SIDE VENT INSTALLATION SEM11 & SEM 21 DUCTING FROM MOTOR TO WALL ELECTRICAL CONNECTION REMOTE CONTROL OPERATION... -
Page 4: Before You Install
BEFORE YOU INSTALL - DUCTING INFORMATION Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory such as flexible ducting, Sirius will only warrant the rangehood and motor. If installation is found to be the cause of failure or issue then charges will apply for service and parts. Flexible ducting is not permitted under any circumstances. -
Page 5: To The Attention Of The User
TO THE ATTENTION OF THE USER • This appliance must not be used over cook tops powered by wood or coal or in any case, over cook tops with power levels that could damage This rangehood is designed to work with ducted the appliance. -
Page 6: Pre-Installation Checks
NOTE Check PARTS LIST on page 26 for all included parts prior to discarding packaging. PRE-INSTALLATION CHECKS Connect all of the electrical components to the unit and motor to make sure both the unit and the motor are functioning properly (see page 15 for instructions). Remove all connections and proceed with installation if both unit and motor are fully operational. -
Page 7: Before You Install
BEFORE YOU INSTALL Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory such as flexible ducting, Sirius will only warrant the hood and motor. If installation or inferior parts are found to be the cause of failure or issue then charges will apply for service and parts. -
Page 8: Attaching The Pendant Light
ATTACHING THE PENDANT LIGHT Step 1d: Feed the cables through the four holes Step 1a: The Filter Cover is held in place via four in each corner of the rangehood ensuring that the magnets. Accessibility to the filters is achieved by labelled + positive and - negative cables go into the gently pulling down on the cover as per fig.1 correct holes. -
Page 9: Line Measurements
LINE MEASUREMENTS FOR CEILING CUTOUTS AND MOUNTING HOLES Fig.7 NOTE As every installation will differ slightly depending on the ceiling cavity of the dwelling, this installation shall be used as a guide only. • These cassettes are held in place with the use of the 4 x 250mm threaded bolts. -
Page 10: Installing The Timber Support Beams
INSTALLING THE TIMBER SUPPORT BEAMS • After running the timber support beams in the cavity above, pre-drill 4 x 8mm holes through the timber and pass the 4 x 250mm bolts through them, ensuring that the larger washer is on the INSIDE OF THE CEILING CASSETTE. -
Page 11: Motor And Venting Options
MOTOR AND VENTING OPTIONS: SLT977EMEL, SLT978EMEL (150mm DUCTING) SEM11 SEM21 SEM51 Note: Roof vent option shown. Motor can be a maximum 2 metres from For SEM51 installation, please see manual on Motor can also be wall or eave vented. ground level. www.siriusbrand.com NOTE Motor MUST be accessible for servicing at all times. -
Page 12: Top Vent Installation
TOP VENT INSTALLATION 1. Knock out the 150mm plate on the top of the unit and attach the 150mm adaptor plate (Part ‘A’) 1. Use 150mm ducting. 2. The ducting fits directly onto the collar on the top adaptor plate (Part ‘A’). 3. -
Page 13: Side Vent Installation
SIDE VENT INSTALLATION: 150mm DUCTING: SEM11 MOTOR (INTERNAL) 1: Knock out the 150mm plate on the chosen long or short side of the unit & attached the 150mm adaptor plate (Part ‘A’) 2A: Connect the length of ductwork (Part ‘E’) directly to Part ‘A’, then secure with a universal ring clamp (Part ‘D’). -
Page 14: Ducting From Motor To Wall
DUCTING FROM MOTOR TO EXIT POINT: (SEM11) After completing the ducting from the Rangehood to the motor location, either a roof, wall or eave exit point can be used. To see the range of Easykits available please head to www.siriusbrand.com or contact your retailer. -
Page 15: Electrical Connection
ELECTRICAL CONNECTION 10AMP GPO POWER CEILING CASSETTE CABLE FROM MOTOR MOTOR CONNECTION WIRING BOX MOTOR MOTOR WIRING CONNECTION 1. Remove the four screws holding the front of the housing in place to expose the connections. 2. Following the wiring chart on the fron of the housing, connect each wire to the matching colour, making sure that this is done correctly before running power to the unit. -
Page 16: Remote Control
REMOTE CONTROL Set-up: Dimmable lights function: 6 channel control for rangehood remote. SLT977EMEL, SLT978EMEL models only This function provides for lights dimmability, ranging • When the rangehood is first turned on, hold the from 20% to 100%, by continuously pressing the lighting button for 5 seconds. -
Page 17: Operation
OPERATION MODE Standard configuration: Standard configuration requires all rangehood radio control systems to be provided with the same transmission code. In the event two rangehoods are installed in the same room or nearby, each system may affect the operation of the another. Therefore, the code of one radio control system must be changed. -
Page 18: The Sirius App
THE SIRIUS APP CREATE YOUR ACCOUNT ON SIRIUS APP. DOWNLOAD SIRIUS APP FOR ANDROID 1. From Home App, Tap on Join now. 1. Open the Google Play Store App 2. Search or browse for SIRIUS App. 3. Select it. 4. Tap to Install. 5. - Page 19 4. Go to your e-mail address and Confirm your PAIRING YOUR PRODUCT account. Fast way using the WPS procedure, if your router has no WPS button, please follow the next instructions. PAIRING WPS MODE 1. After Login Tap the App Menu (top left) and select DEVICES.
- Page 20 3. Tap USE WPS MODE. 6. Press DONE on WPS description. 7. Use the QR code reader to connect the product with the App, using the label on the brochure or using the label located inside the product, found on the motor when you remove the grease filters.
- Page 21 PAIRING MANUAL MODE 3. Tap ENROLLMENT_DIRECT_MODE 1. After Login Tap the App Menu (top left) and select DEVICES 2. Tap ADD NEW DEVICE 4. ON YOUR RANGE HOOD: • Switch off completely (light and motor) • Hold button for 3 secs for settings menu LEDs will flash) •...
- Page 22 6. Connect to “HOOD network” inserting as 10. IN CASE OF FOLLOWING ERROR: passwork “password”. Go back to the home page. 7. TURN BACK TAP “Claim Devices”. 8. ENTER WI-FI NAME AND WI-FI PASSWORD 9. TAP CONFIGURE...
- Page 23 11. Use the QR code reader to connect the product REMOVE ONE DEVICE FROM APP with the App, using the label on brochure or using the 1. After Login Tap the App Menu (top left) and label located inside the product, visible by removing select DEVICES the grease filters.
- Page 24 FUNCTIONS LIGHT Timer Slide the toggle switch for switching ON/OFF. Tap on and set the minutes for shutting down -:-:- the device. Slide the scrollbar for setting the colour temperature (°K) Fan speed Tap on the speed you want, select ‘0’ for switching OFF.
- Page 25 RENAME DEVICE SHARE DEVICE Tap on and rename device. Tap on and share device only to subscribed account.
-
Page 26: Parts List
PARTS LIST (INCLUDED) PART A PART B 150mm adaptor plate 10mm Adaptor mounting screws PART C Threaded support bars... -
Page 27: Optional Parts List
OPTIONAL PARTS LIST PART D PART E Universal ring clamp Semi rigid aluminium ducting 150mm URC25-215/325 SRPRO 30/150... -
Page 28: Wiring Diagrams
WIRING DIAGRAM: SLT977EMEL, SLT978EMEL... -
Page 29: Warranty
WARRANTY INFORMATION Dear Customer, Thank you for choosing this Sirius Rangehood. We are sure that it will provide you with many years of excellent service. At Arisit Pty Limited we are dedicated to ensuring that our customers receive the best possible after-sales care. The Sirius ‘Protection Plan’... - Page 30 Your Warranty Register now to qualify. Terms & Conditions This warranty will not apply where: Division or travel costs for a technician or The fault is caused by accident, Authorised Service Agent shall be for the misuse, an infestation of insect account of the Purchaser.
