- Page 1 Congratulations on your purchase! Thank you for choosing a Sirius product. SLT969 ceiling cassette user manual INSTALLATION AND USE INSTRUCTIONS SLT969 EAN #9351116002077 SLT969 WH EAN #9351116002084...
-
Page 2: Table Of Contents
BEFORE YOU INSTALL TO THE ATTENTION OF THE USER PRE-INSTALLATION CHECKS OPENING THE GLASS PANEL INSTALLATION DUCTING THE CASSETTE REMOTE CONTROL WIRING DIAGRAM WARRANTY The symbol on the product or on its packaging indicates that this product may not be treated as house-hold waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 3: Before You Install
CAUTION BEFORE YOU INSTALL – please read Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory such as flexible ducting, Sirius will only warrant the hood and motor. If installation is found to be the cause of failure or issue then charges will apply for service and parts. -
Page 4: To The Attention Of The User
TO THE ATTENTION OF THE USER This rangehood is designed to work with ducted outside evacuation. WARNING • This appliance must not be used over cook tops Keep these instructions for use with the appliance. If powered by wood or coal or in any case, over the appliance should be sold or passed on to others, cook tops with power levels that could damage make sure that the instructions are passed on with... -
Page 5: Pre-Installation Checks
PRE-INSTALLATION CHECKS Connect all of the electrical components to the unit and motor to make sure both the unit and the motor are functioning properly. (NOTE: The motor plug is fitted with a dummy plug - with the exception of SEM1 motor - to protect the connection from dust. - Page 6 WARNING Before proceeding with the installation of the ceiling cassette, please thoroughly inspect the entire unit (including the motor) for any damages, including all of the electrical connections. If any damage is found, cease installation and report it immediately to the retail partner that the cassette was purchased from. NOTE •...
-
Page 7: Opening The Glass Panel
OPENING THE GLASS PANELS - SLT969 On the side where the speed control light is visible, plull down the centre of the panel. This panel is held on by a strong magnet. Allow the panel to swing open to expose the grease filters. (Fig. 1) Panel drops down Fig. -
Page 8: Installation
INSTALLATION NOTE As every installation will differ slightly depending on the ceiling cavity of the dwelling, this installation instruction shall be used as a guide only. 1. Horizontal support beams need to be installed in the cavity above to support the weight of the cassette. (Fig 3.) Timber support beams (not supplied) Fig. -
Page 9: Ducting The Cassette
3. Fix the top section of the mounting brackets to the horizontal support beams in the ceiling, taking measurements to make sure theu are aligned with the brackets already attached to the cassette. 4. Lift the cassette to the desired height and fix in place with the use of the 10mm supplied screws that are inserted on the sides of the mounting brackets. -
Page 10: Remote Control
REMOTE CONTROL OPERATION MODE Standard configuration: Working: Standard configuration requires all rangehood radio 6 channel control for rangehood remote. control systems to be provided with the same transmission code. In the event two rangehoods are • When the rangehood is first turned on, hold the installed in the same room or nearby, each system lighting button for 5 seconds. -
Page 11: Wiring Diagram
SLT969 WIRING DIAGRAMS... -
Page 12: Warranty
CLEANING AND MAINTAINENCE 1. Cleaning the filters in the dishwasher. • Clean the mesh filters by removing them from the cassette by pulling on the tab and dropping them down. • Run them through a cycle in the dishwasher. Once the cycle is completed ensure that they have air dried completely and replace them into the cassette.
