- Page 1 Congratulations on your purchase! Thank you for choosing a Sirius product. Ceiling cassette user manual INSTALLATION AND USE INSTRUCTIONS SLT958 EM EAN #9351116001292 SLT958 EM WH EAN #9351116001780 SLT952 EM EAN #9351116001018 SLT968 EM EAN #9351116002053 SLT968 EM WH EAN #9351116002060 SLT960 EM EAN #9351116000936...
-
Page 2: Table Of Contents
CAUTION BEFORE YOU INSTALL – please read Sirius warranty covers only Sirius product. If you choose to install a non-Sirius branded accessory BEFORE YOU INSTALL such as flexible ducting, Sirius will only warrant the hood and motor. If installation is found to be the cause of failure or issue then charges will apply for service and parts. -
Page 3: Before You Install
TO THE ATTENTION OF THE USER NOTE This rangehood is designed to work with ducted Check PARTS LIST on page 20 for all included outside evacuation. parts prior to discarding packaging. WARNING PRE-INSTALLATION CHECKS Keep these instructions for use with the appliance. If •... -
Page 4: Opening The Glass Panels
WARNING OPENING THE GLASS PANELS - SLT960 EM OPENING THE COVER PANELS - SLT958 EM, Before proceeding with the installation of the ceiling cassette, please thoroughly inspect the entire unit SLT958 EM WH, SLT968 EM, SLT968 EM Step 1a: Accessibilty to the filters is done by pulling (including the motor) for any damages, including all of the electrical connections. -
Page 5: Line Measurements
LINE MEASUREMENTS FOR MOUNTING HOLES INSTALLING THE TIMBER SUPPORT BEAMS • After running the timber support beams in the cavity above, pre-drill 4 x 8mm holes through the timber and pass the 4 x 250mm bolts through them, ensuring that the larger washer is on the INSIDE OF THE CEILING CASSETTE. -
Page 6: Motor And Venting Options
MOTOR AND VENTING OPTIONS: TOP VENT INSTALLATION SLT958 EM (150mm DUCTING) 1. Use 150mm ducting (Part ‘K.1’) for SLT958 EM models or 200mm ducting (Part ‘K.2’) for SLT952 / SLT960 EM / SLT968 EM models. SEM 1 SEM 2 SEM 5 2. -
Page 7: Side Vent Installation
SIDE VENT INSTALLATION: SLT958 EM SIDE VENT INSTALLATION: SLT952 EM, SLT968 EM, SLT960 EM 150mm DUCTING: SEM 1 MOTOR (INTERNAL) 200mm DUCTING: SEM 7 MOTOR (EXTERNAL) • Ensure that the unused side and top ports are blocked off using the supplied blocking panels •... -
Page 8: Remote Control
REMOTE CONTROL OPERATION MODE DUCTING FROM MOTOR TO WALL VENT: (SEM 1 and SEM 8) Standard configuration: Working: 1. Run the length of ducting to the motor. (Additional lengths of ducting can be attached using an Standard configuration requires all rangehood radio 6 channel control for rangehood remote. -
Page 9: Wiring Diagrams
WIRING DIAGRAM: SLT952 EM WIRING DIAGRAM: SLT968 EM... -
Page 10: Parts List
PARTS LIST (INCLUDED) PARTS LIST (NOT INCLUDED) PART G PART F PART A PART B 150mm to 200mm Duct expander Universal ring clamp Side vent adapter Side vent cover GDR 150/200 URC25-215/325 PART J PART H PART C PART D 150mm diameter connector piece 200mm diameter connector piece Top bracket... -
Page 11: Warranty
ARISIT PTY LIMITED (Australia) www.arisit.com Sirius Hoods and ducting products are only available from our select group of Sirius Professional Stockists ABN 23 091 515 294 nationwide. For the latest list of Sirius Stockists www.arisitwarranties.com.au 40-44 Mark Anthony Drive near you, please refer to www.siriusbrand.com Dandenong South VIC 3175 www.siriusbrand.com...
