Instructions - Parts
Modbus TCP
Gateway Module
For use with systems based on Graco Control Architecture to provide Modbus TCP
communications capabilities.
Important Safety Instructions
Read all warnings and instructions in the system
operation manual. Save these instructions.
RECOGNIZED
COMPONENT
Conforms to
UL STD 508
C
US
Certified to CAN/CSA STD C22.2 No. 14
4003764
334183B
EN
Advertisement
Table of Contents
Related Manuals for Graco Modbus TCP
Summary of Contents for Graco Modbus TCP
- Page 1 Instructions - Parts Modbus TCP Gateway Module 334183B For use with systems based on Graco Control Architecture to provide Modbus TCP communications capabilities. Important Safety Instructions Read all warnings and instructions in the system operation manual. Save these instructions. RECOGNIZED...
-
Page 2: Table Of Contents
Technical Data ......10 Graco Standard Warranty ....12 Graco Information . -
Page 3: Component Identification
Component Identification Component Identification Front Back Fieldbus Connector (C) Modbus TCP TI11814A . 1: Key: Communications Gateway Module Base Fieldbus Connector Module Connection Screws Access Cover Module Status LEDs Fieldbus Status LEDs (see descriptions on page 7) CAN Connectors 334183B... -
Page 4: Overview
Module Requirements The Modbus TCP (MBTCP) Gateway Module provides a Power Supply control link between a Modbus TCP fieldbus and a sys- tem that uses Graco Control Architecture (GCA). This The MBTCP Gateway Module requires a 12-30 VDC @ link provides the means for remote monitoring and con- 0.2 A power supply. -
Page 5: Installation
Installation Installation 3. Insert and press software token (T) firmly into slot. The MBTCP Gateway Module is available for use with all GCA-based systems that have a compatible design. Each MBTCP module requires the following to operate in a system: •... - Page 6 Installation Rotary Switch If your system has only one MBTCP module, keep the rotary switch (S) at its default position of 0. If the system has multiple MBTCP modules, use a unique value (position) for each module. Remove the access cover (E) to set the rotary switch (S) for each module.
- Page 7 Installation Fieldbus Connectors Item Ref. Network Status LED Module Status LED Link/Activity Ethernet Interface Network Status LED LED State Description No power or no IP address Green Connection established. Module is in the Process Active state or the Idle state. Flashing Green Waiting for connection Duplicate IP address or FATAL event...
-
Page 8: Troubleshooting
Troubleshooting Troubleshooting MBTCP Module Errors Module errors are triggered by overall system operation. The module status LED blinks red at a frequency of 1 Hz. The red LED (F) will flash a code, pause, then repeat. Module Status LED Signal Diagnosis Solution 3 red flashes The host of the mapped property is... - Page 9 Troubleshooting Modbus Errors Modbus errors are typical protocol errors defined by fieldbus specification. The fieldbus error code shown is returned to the PLC when the error condition occurs. Code Name Cause Solution Illegal Function Request function is not supported. Use supported Modbus functions: •...
-
Page 10: Parts
Parts Parts Modbus TCP Gateway Module Parts Ref Part No. Description Qty. 24W777 MODULE, Gateway, Modbus TCP 289697 Base 114135 SCREW, mounting, module connec- tion 277674 COVER, access Technical Data Category Data Power requirements 12-30 VDC @ 0.2 A Weight 12.8 oz. - Page 11 334183B...
-
Page 12: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
