POWER LED
ALARM LED
Port Status LEDs
Power Supply Terminal Block
RS-232 Serial Console Port
Failsafe Alarm Relay
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RS940GF:
AC or DC power cord (16 AWG)
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
4 x #6-32 screws
1.4

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated Configuration Manual.
RUGGEDCOM RS940GF
Installation Manual, 01/2021, C79000-G8976-1356-04
Illuminates when power is being supplied to the device.
Illuminates when an alarm condition exists.
Indicate the status of the optional SFP ports:
Solid
Blinking
Off
Status LEDs for copper Ethernet ports are incorporated into each
RJ45 port. For more information, refer to
(Page
21)".
A pluggable terminal block. For more information, refer to:
"Connecting Power (Page 13)"
"Power Supply Specifications (Page 25)"
The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
"Connecting the Failsafe Alarm Relay (Page 12)"
"Failsafe Alarm Relay Specifications (Page 25)"
Tools/Materials
1.3 Required Tools and Materials
State
Link
Activity
No link/activity
19)".
Purpose
For connecting power to the device.
For connecting the device to the network.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
Introduction
Description
"Copper Ethernet Ports
