Keypad long presses for module status
In addition, some of the information can be retrieved on the Simon XT via long key presses from the keypad. Press and
hold the following panel keys for 10 seconds to display the given information on the panel display. Most messages are
displayed for less than 30 seconds but can be cut short by pressing [#] for 10
seconds.
Key
1 Key
2 Key
3 Key
5 Key
6 Key
8 Key

Troubleshooting LEDs

Status LEDs indicate network and module status. Figure 5 below shows the location of the status LEDs on the LTE
module.
Figure 5: Status LEDs
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Simon_XT/Interlogix_Simon_XT_...
Function
15-digit module serial number. This number is needed to
create the Alarm.com customer account.
Module firmware version. (e.g.,
4183a)
Performs Phone
Test
Wireless signal strength level and module status or error,
if any. The panel will display bars for the signal level
(zero to five) and a number (2 to 31) followed by the
Mode it is in. (See LTE Module
Statuses).
Battery voltage as read by the module, to two decimal
places, and the AC power status. (e.g. Battery: 6.79v,
AC Power OK)
LTE frequency used by the module: High = 1700MHz;
Low = 700
MHz.
