Default Switch and Jumper Settings

DIP Switch SW11 User GPIO

See
Figure A-1
X-Ref Target - Figure A-1
Table A-1: SW11 Default Switch Settings

DIP Switch SW13 Mode and Flash Address Settings

See
Figure A-2
X-Ref Target - Figure A-2
KC705 Evaluation Board
UG810 (v1.3) May 10, 2013
Figure 1-2, page 8 Item 24 for location of SW11. Default settings are shown in
and details are listed in
ON Position = 1
Figure A-1: SW11 Default Settings
Position Function
1 GPIO_DIP_SW3
2 GPIO_DIP_SW2
3 GPIO_DIP_SW1
4 GPIO_DIP_SW0
Figure 1-2, page 8 Item 29 for location of SW13. Default settings are shown in
and details are listed in
ON Position = 1
Figure A-2: SW13 Default Settings
www.xilinx.com
Table A-1.
1 2 3 4
GPIO DIP SW
OFF Position = 0
UG810_aB_01_010512
Default
Off
Off
Off
Off
Table A-2.
1 2 3 4 5
OFF Position = 0
UG810_aB_02_010512
