Table 3.22. J31: M22 Key-M Slot
GSPI-Q3700-LLVA User's Manual
PIN No. Description
1 Ground
3 Ground
5 RX3_N
7 RX3_P
9 Ground
11 TX3_N
13 TX3_P
15 Ground
17 RX2_N
19 RX2_P
21 Ground
23 TX2_N
25 TX2_P
27 Ground
29 RX1_N
31 RX1_P
33 Ground
35 TX1_N
37 TX1_P
39 Ground
41 RX0_N/SATA_B+
43 RX0_P/SATA_B-
45 Ground
47 TX0_N/SATA_A-
49 TX0_P/SATA_A+
51 Ground
53 CLK_N
55 CLK_P
57 Ground
59 KEY-M
KEY-M
61
KEY-M
63
KEY-M
65
67 N/C
PIN No. Description
2 3.3V
4 3.3V
6 N/C
8 N/C
10 LED#
12 3.3V
14 3.3V
16 3.3V
18 3.3V
20 N/C
22 N/C
24 N/C
26 N/C
N/C
28
N/C
30
N/C
32
N/C
34
N/C
36
DEVSLP
38
N/C
40
N/C
42
N/C
44
N/C
46
N/C
48
PERST#
50
CLKREQ#
52
PEWAKE#
54
N/C
56
N/C
58
KEY-M
60
KEY-M
62
KEY-M
64
KEY-M
66
SUSCLK
68
