Data Networks A And B; Data Network A Cabling - Dell EMC ScaleIO Ready Node 14G Hardware Installation Manual

Figure 38 Data networks A and B
Data Switch B
4
Data Switch A
2
iDRA
C
2
iDRA
C
Table 19 Data network A cabling
Source
Node 1 Onboard Port 0
Node 2 Onboard Port 0
Node 3 Onboard Port 0
Node 4 Onboard Port 0
Node 5 Onboard Port 0
Node 6 Onboard Port 0
Node 7 Onboard Port 0
Node 8 Onboard Port 0
Node 9 Onboard Port 0
Management Server Port 0
Node 10 Onboard Port 0
31
29
Mgmt Server
1
0
Node 17
Node 1
0
Data Network A
Data Network Switch A Port 2
Data Network Switch A Port 6
Data Network Switch A Port 10
Data Network Switch A Port 14
Data Network Switch A Port 18
Data Network Switch A Port 22
Data Network Switch A Port 26
Data Network Switch A Port 30
Data Network Switch A Port 34
Data Network Switch A Port 48
Data Network Switch A Port 1
Data network A wiring for 2U1N configuration
Wiring Diagrams for a 2U1N Configuration
48
48
Destination
40 G link to
core switch
40 G link to
core switch
40 G link to
core switch
83
