Install Management Network I/O Cables
Hardware Installation Guide
52
Table 10 Management A, nodes 1 -16 cabling (continued)
Source
Node 4 MGMT1
Node 5 BMC (iDRAC)
Node 5 MGMT1
Node 6 BMC (iDRAC)
Node 6 MGMT1
Node 7 BMC (iDRAC)
Node 7 MGMT1
Node 8 BMC (iDRAC)
Node 8 MGMT1
Node 9 BMC (iDRAC)
Node 9 MGMT1
Node 10 BMC (iDRAC)
Node 10 MGMT1
Node 11 BMC (iDRAC)
Node 11 MGMT1
Node 12 BMC (iDRAC)
Node 12 MGMT1
Node 13 BMC (iDRAC)
Node 13 MGMT1
Node 14 BMC (iDRAC)
Node 14 MGMT1
Node 15 BMC (iDRAC)
Node 15 MGMT1
Node 16 BMC (iDRAC)
Node 16 MGMT1
Data SwitchA <...> Port
Data SwitchB <...> Port
Data SwitchA MGMT Port
Data SwitchB MGMT Port
Management Server NIC1
Link to Core Switch or Management SwitchB
Destination
Management SwitchA Port 16
Management SwitchA Port 18
Management SwitchA Port 20
Management SwitchA Port 22
Management SwitchA Port 24
Management SwitchA Port 26
Management SwitchA Port 28
Management SwitchA Port 30
Management SwitchA Port 32
Management SwitchA Port 34
Management SwitchA Port 36
Management SwitchA Port 1
Management SwitchA Port 3
Management SwitchA Port 5
Management SwitchA Port 7
Management SwitchA Port 9
Management SwitchA Port 11
Management SwitchA Port 13
Management SwitchA Port 15
Management SwitchA Port 17
Management SwitchA Port 19
Management SwitchA Port 21
Management SwitchA Port 23
Management SwitchA Port 25
Management SwitchA Port 27
Management SwitchA Port 45
Management SwitchA Port 46
Management SwitchA Port 47
Management SwitchA Port 48
Management SwitchA Port 38
Management SwitchA Port 52
