Introduction

AVERTISSEMENT : Le FOX3 émet une lumière invisible en continu (conforme à la
•
•
•

About this Guide

This guide contains installation, configuration, and operating information for the Extron
FOX3 Matrix Switchers. These customizable matrix switchers support Extron fiber optic
endpoints (transmitters and receivers) up to:
•
•
•
•
•

About the FOX3 Matrix Switchers

The FOX3 Matrix Switcher (see
to one or more optical outputs. The matrix switcher can route multiple input/output
configurations simultaneously. The switcher is configurable, assembled from individual
input/output (I/O) boards, each of which supports 8 inputs and 8 outputs.
The FOX3 Matrix Switchers are compatible with the FOX3 endpoints.
WARNING: The FOX3 matrix switcher outputs continuous invisible light (Class 1
rated), which may be harmful to the eyes; use with caution.
Do not look into the rear panel fiber optic cable connectors or into the fiber optic
•
cables themselves.
• Plug the attached dust cap into the optical transceiver when the fiber optic cable is
unplugged.
classe 1) qui peut être dangereuse pour les yeux , à utiliser avec précaution.
• Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau arrière
ou dans les câbles fibre optique eux-mêmes.
Branchez la protection contre la poussière dans l'ensemble émetteur/récepteur
•
lorsque le câble fibre optique est débranché.
About this Guide
About the FOX3 Matrix Switchers
Features
FOX3 Matrix 24x — 24 inputs and outputs.
FOX3 Matrix 40x — 40 inputs and outputs.
FOX3 Matrix 80x — 80 inputs and outputs.
FOX3 Matrix 160x — 160 inputs and outputs.
FOX3 Matrix 320x — 320 inputs and outputs.
figure 1 on page 2) distributes optical input signals
FOX3 Matrix Series Switchers • Introduction 1
