System Definitions

] = CR/LF (carriage return/line feed) (hex 0D 0A)
= Carriage return or pipe symbol (no line feed, hex
|
}
or
0D)
E =
Escape key, or hex 1B (use W instead of
web browsers, or at any time)
• = Space
*
= Asterisk character
= Input number — 00 to max number of inputs
X!
(Input = 0 Untie)
X# = Output number — 00 to max number of outputs
(Output = 0 Untie)
X$ = Enable or Disable —
0 = Off/disable
1 = On/enable
X^ I/O board type —
0 = No board detected
1 = Active MM board
2 = Active SM board
5 = Unknown
= I/O board slot number — 1 to maximum number
X&
of slots (3 for 24x, 5 for 40x, 10 for 80x,
20 for 160x, 40 for 320x)
X( = Active Fiber Link detection — SFP A/B "IN LED"
Active signal detection (SFP A/B "IN LED") —
X1) =
0 = Not detected
1 = Detected
NOTE:
SFP A and B "OUT LED" is always active.
= Audio gain/attenuation value — -18 to +24
X1#
= Mute status —
X1$
0 = Off (unmuted)
1 = On (muted)
X1% Video/Audio mute status —
0 = No mute
1 = Video mute
2 = Audio mute
3 = Both video and audio mute
X1^ = Volume adjustment range — 0 to 100
(approximately 1 dB per step 0% to 100% [default])
X1*
SFP modules installed —
0 = No SFP
1 = MM SFP
2 = SM SFP
3 = Unknown SFP
X1( =
X2)
E
for
X2! =
X2$ =
X2% =
X2^ =
X2&
X2* =
X3% =
X3^ =
X3& =
X3* =
=
X3(
X34) =
FOX3 Matrix Series Switchers • SIS Configuration and Control
Video signal status —
0 = No video signal at input
1 = Video Input signal detected
Verbose mode —
0 = Clear/none (default)
1 = Verbose mode
2 = Tagged response for queries
3 = Verbose mode and tagged responses for
queries
Timeout — The number of seconds before
timeout on IP connections (min = 1, max = 65000
[default = 30 = 300 seconds]).
Power supply voltage —
P = Primary is listed first
R = Redundant is listed second
Temperature — Degrees Fahrenheit and Celsius
xx.x • xx.x
F C)
(example:
Fan speed — Revolutions per Minute - RPM
xxx
(example: RPM)
Power supply status —
0 = Power Supply inactive/not installed
1 = Power Supply active/installed
2 = Power Supply failed/installed
Maximum virtual video matrix size
(InputxOutput) — Example: 80x80
Audio input number — 00 to max number of
inputs or Expansion 30001-30008, Dante 40001-
40032, Analog 50001-50004
Audio output number — 00 to max number of
outputs or Expansion 30001-30008, Dante 40001-
40032, Analog 50001-50004
Return audio source number — 00 to max
number of outputs (from an Rx unit, Expansion
30001-30008, Dante 40001-40032, or
Analog 50001-50004)
Analog audio destination number (to Tx) — 00
to max number of inputs
Return audio source number — 00 to max
number of inputs (Analog 50001-50004)
Analog audio output number — 00 to max
number of outputs (Analog 50001-50004)
