G4 Industrial Tap
User Guide
Tap Operation...................(Pages 2-7)
•
LCD Screen & Menu .......(Pages 8-19)
•
Maintenance.................... (Pages 20-21)
•
Date of Installation............/........./..........
Affix Model Number Label
802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00
Here
802743NZ
Page 1 of 24

Advertisement

Table of Contents
loading

Related Manuals for Zenith G4

Summary of Contents for Zenith G4

  • Page 1 User Guide Tap Operation....(Pages 2-7) • LCD Screen & Menu ..(Pages 8-19) • Maintenance....(Pages 20-21) • Date of Installation..../../..Affix Model Number Label Here 802743NZ 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 1 of 24...
  • Page 2 To control the safety (From the touch screen): (see page 19) For Hot Isolation: (see page 19) Page 2 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...
  • Page 3 To Enable or Disable the safety on the tap 5. Press button to select Enable / Disable For Hot Isolation (see page 19) 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 3 of 24...
  • Page 4 Upper RED button for dispensing boiling water Lower BLUE button for dispensing chilled water Page 4 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...

  • Page 5: Tap Operation

    15 seconds (This is user adjustable). Releasing the button will stop the flow of water and will allow the unit to reset for repeat operations. 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 5 of 24...
  • Page 6 5 and 15 seconds (This is user adjustable). Releasing the button will stop the flow of water and will allow the unit to reset for repeat operations. Page 6 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...

  • Page 7: Filter Light

    ‘C’ of this document. Safety light: Safety light ON: No boiling water will be dispensed unless the safety button and the Red button are pressed Safety Light simultaneously. 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 7 of 24...

  • Page 8: Lcd Screen

    Note: When selecting Menu options, the screen will revert to the main menu, if the screen remains inactive for a period, in excess of 10 seconds. Page 8 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...

  • Page 9: Lcd Screen Menu

    (Months) • Filter Settings • Sleep Mode • Energy Modes Options • Safety • Safety Lock • Dispense Times • Hot Isolation • Hot/Cold Dispensing 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 9 of 24...
  • Page 10 Press [Filtert Log] to view the system’s filter log. Press [<=] button for the previous menu or press [Home] button to return to the home screen. Page 10 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...
  • Page 11 LCD Screen operation - Section C Install Once your Zenith HydroTap G4 unit has been installed, Go to Install menu to configure the system settings for your product. Sub menu: - Filter Flush - Filter Reset - Boiling Calibration - Booster...
  • Page 12 Booster is warm. Otherwise select NO, if no Booster is installed Note: Failing to make the correct selection for ‘Booster’ will effect product performance. Page 12 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...
  • Page 13 This section is reserved for service technicians only Note : Call a licensed electrician, plumber,or Zenith office on 0800 558055, for assistance, service, spare parts, or enquiries. 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 13 of 24...
  • Page 14 HydroTap unit. LCD Screen operation - Section F F Communication (when available) The Zenith HydroTap G4 allows the user to use wifi to monitor and control the product remotely. Not yet available Page 14 of 24...

  • Page 15: Set Temperature

    Set Temperature Zenith HydroTaps are designed to operate within 1ºC to 2ºC of set point for boiling water and between 5ºC to 9ºC for chilled drinking water. All boiling water units are self calibrating to 98ºC, which is the recommended setting.
  • Page 16 Filter Zenith HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change.

  • Page 17: Energy Modes

    The unit will return to sleep mode after 2 hours of non use. Please allow sufficient time for the water to reach the set temperature after disabling the sleep mode. 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 17 of 24...
  • Page 18 Note: Any attempt, during OFF mode, to dispense water, will bring the unit out of energy mode. The system will revert to the energy mode setting after 30 minutes of non use. Page 18 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...
  • Page 19 • If the Hot Isolation is not re-enabled, it will be automatically re-enabled after 30 seconds of inactivity. Note: Hot Isolation - cannot be activated or deactivated from the IT - Two button tap. 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 19 of 24...

  • Page 20: Filter Maintenance

    Filter Maintenance Water Filter The Zenith HydroTap notifies when filter replacement is due. If you notice one of the following, you will need to change the filter: • The Change Filter light will flash white once a second and remain so until reset.

  • Page 21: Air Inlet Filter

    Air Inlet Filter The Zenith HydroTap air filter is conveniently located on the outside of the condenser. The filter screen is a sliding fit in the plastic housing on the left hands side of the under sink unit. The screen may be removed for cleaning, by sliding it forward.

  • Page 22: Home Menu Icons

    BOILING 98°C Chilled Temperature The set temperature of the water in the Chiller tank will be displayed. This is will range from 5-9°C CHILLED 5-9°C Page 22 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...
  • Page 23 Notes 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00 Page 23 of 24...

  • Page 24: Contact Details

    AU675601, AU637412, AU635979, GB0422305, GB2065848, US4354049, US5103859, US5099825 and SA2006/08043. Other patents are in force and patent applications are pending. Page 24 of 24 802743NZ - HT G4-BC-IS-IT, User Guide - Aug 2015 - V2.00...
