HydroTap G4
User Guide
Tap Operation..................(Pages 2-8)
•
LCD Screen & Menu .......(Pages 9-19)
•
Maintenance.................... (Pages 19-22)
•
Date of Installation............./........../...........
CS Commercial
Affix Model Number Label
801981NZ - CS User Guide - Aug 2015 v2.00
Here
801981NZ
®
Page 1 of 24
Advertisement
Table of Contents
Related Manuals for Zenith HydroTap G4
Summary of Contents for Zenith HydroTap G4
-
Page 1: User Guide
HydroTap G4 ® User Guide Tap Operation....(Pages 2-8) • LCD Screen & Menu ..(Pages 9-19) • Maintenance....(Pages 19-22) • Date of Installation...../../... CS Commercial Affix Model Number Label Here 801981NZ 801981NZ - CS User Guide - Aug 2015 v2.00... - Page 2 Tap functions HydroTap Classic: Chilled Lever Sparkling The HydroTap Classic uses lever Lever controls, to dispense Chilled and Chilled Sparkling water. There are Blue indicator lights, built Filter light into the levers, to show the status of the chilled water. There is a filter warning light to indicate when a filter change is due NOTE: The safety button on all...
- Page 3 Tap functions All-In-One Tap: The top of the All-In-One tap is operated the same as a Classic HydroTap. The two levers are used for dispensing Chilled and Chilled Sparkling water. The Mixer tap lever is operated as a classic ‘Flick Mixer’. The hot side is marked with a red mark and the cold side with a blue mark, for dispensing cold to warm water.
- Page 4 Tap functions HydroTap Arc/Cube: On powerup, wait 30secs. for the unit to calibrate. Tapping the select button will allow the selection of either the Chilled (BLUE) or Sparkling (White) water mode. The Arc/Cube control may be rotated in a forward or reverse direction to dispense Sparkling or Chilled water.
-
Page 5: Tap Operation
Tap operation To dispense chilled water: (Classic and AIO Taps) Press or Pull the Chilled lever To dispense Chilled water: Depressing the “Chilled” lever allows the dispensing of Chilled water. Pulling forward the lever allows the tap to operate in a “no-touch” mode. Water will flow from between 5 and 15 seconds (This is user adjustable). - Page 6 Tap operation To dispense Sparkling water: (Classic & AIO taps) To dispense Sparkling Press or Pull the Sparkling lever water: Depressing the ‘Sparkling’ lever allows the dispensing of Sparkling water. Pulling forward the lever allows the tap to operate in a in a “no-touch”...
-
Page 7: Tap Lights
Tap lights Blue Chilled Water Light: Blue Lights (Classic & AIO taps) On all the time: This indicates that the temperature of the chilled water is within the set temperature range. Flashing slowly: This indicates that the chilled water is not within the set temperature range. - Page 8 Tap lights Indicator Filter light: light HydroTap Arc/Cube: Flashing filter lights: Select light All three tap lights (Safety; Select and Indicator light) will flash every 10 seconds, indicating a Filter change is required. Safety Light Warning: (All) Flashing warning light: When the indicator light flashes fast and continuous, a system fault has occurred.
-
Page 9: Lcd Screen
LCD Screen Zenith HydroTap G4 introduces a ‘TOUCH’ screen for easy setup and operation adjustment. Date and Time Sleep mode icon **Status window Set chilled water temperature Filter usage Other possible messages in status window: Status** Information Notes System Fault... -
Page 10: Lcd Screen Menu
LCD Screen Menu Main Menu Sub Menu Sub Menu Options Section Language • English • Product Info • Product serial • System Faults Information • Lists • Event Log • Filter Flush • Reset options • Filter Reset • Calibration Installation options •... - Page 11 LCD Screen operation - Section A Set Language Press [MENU] for main menu. Press [Language] button. Select an option to change the language Press [<=] button for the previous menu LCD Screen operation - Section B System Information In this section, you can find product information, system faults and filter log messages.
-
Page 12: Filter Flush
Position CLOSED Position The Zenith HydroTap allows the user to adjust the filter life and to edit the filter usage. (See filter details on Page 16 ). Page 12 of 24 801981NZ - CS User Guide - Aug 2015 - v2.00... - Page 13 LCD Screen operation - Section C 2 - Filter Reset After replacing the filter, the counters should be reset Press the [MENU] button for main menu. Press the [Install] button. Press the [Filter Reset] button. In the next screen, press [YES] button if you want to flush the filter.
- Page 14 HydroTap unit. LCD Screen operation - Section F F Communication (when available) The Zenith HydroTap G4 allows the user to use wifi or Bluetooth to operate the product remotely. Not yet available Page 14 of 24...
- Page 15 4. Choose 12 hour mode or 24 hour mode by pressing the square button. The selected mode will be displayed in dark grey colour with a HydroTap G4 Set Date/Time tick box on the right. Screen 5. Press [NEXT] button to set the date and time using the up and down scroll keys.
- Page 16 LCD Screen operation - Section G ions Filter Zenith HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change. When the first of these functions is reached (i.e.
- Page 17 LCD Screen operation - Section G Energy Modes This mode allows the HydroTap to enter into an Energy Saving mode. There are two options available: ‘Sleep’ mode and ‘ON/OFF’ mode. In SLEEP MODE the unit will go to “Sleep” after a 2hr period of inactivity. The Chilled water will be ON or OFF.
- Page 18 LCD Screen operation - Section G In ON / OFF Mode the user may turn the unit ON or OFF at specific times for individual days or alternatively by weekly and/or weekend settings. To activate ON/OFF mode: Press the [MENU] button for main menu.
-
Page 19: Filter Maintenance
Filter Maintenance Water Filter The Zenith HydroTap notifies when a filter replacement is due. If you notice one of the following, you will need to change the filter: • The Change Filter light will flash white once a second and remains so until reset. -
Page 20: Air Inlet Filter
Air Inlet Filter The Zenith HydroTap air filter is conveniently located on the outside of the condenser. The filter screen is a sliding fit in the plastic housing on the side of the under sink unit. The screen may be removed for cleaning, by sliding it forward. - Page 21 Gas bottle change Turn the CO bottle, main control wheel, OFF (Clockwise). Turn the regulator, grey control knob, all the way out (Anti clockwise). Dispense sparkling water for 30 seconds, until the water flow is free of gas Remove the regulator assembly from the bottle by unscrewing the large chrome nut.
-
Page 22: General Cleaning
Cleaning General cleaning Do not use strong, corrosive, spray or abrasive cleaners. Clean with a soft damp cloth and mild soap. Under sink units must never be located near, or cleaned with water jets. Avoid using airborne pesticides near the undersink unit. Page 22 of 24 801981NZ - CS User Guide - Aug 2015 - v2.00... -
Page 23: Home Menu Icons
Home Menu Icons Sleep mode is active. There are 3 sleep mode options which display this icon on the home screen. See page 17 for details. Filter use. This icon displays the filter usage remaining from 100% (New filter) to 0% (end of life). When it reaches 0% the filter warning light on the tap head will flash slowly. -
Page 24: Contact Details
Telephone: 0800 558055 Facsimile: 0800 559055 As Zenith policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
