Thank you for selecting LENNOX air conditioners.Please read this manual
carefully before operation and keep it for further reference.
INSTALLATION/OPERATION
INSTRUCTIONS
VE Air Handler
VRF SYSTEMS
INDOOR UNITS
VEAH024N432P
VEAH030N432P
VEAH034N432P
VEAH038N432P
VEAH048N432P
007
N
Voltage Rating
K
230/60/3 and 220/50/3
N
380V/50-60Hz/3Ph
G
460V/60Hz/3Ph
Y
230V/60Hz/3Ph
T
220V/50Hz/1Ph
P
230V/60Hz/1Ph
U
220V/50-60Hz/1Ph
And valid combinations
(see instructions inside)
4
32
P
HW
UM
CC
4C
1C
2C
HD
SD
LD
GD
AH
OA
Available digit for future ref.
Evaporator Types
Hi-Wall
Universal Mount
Compact Cassette
4-Way Cassette
1-Way Cassette
2-Way Cassette
High Static Fan Coil
Slim Fan Coil
Low Static Fan Coil
Large Fan Coil HS
Thank you for selecting
Air Handler
Outside Air
