NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board should be
populated with DIMMs that support the Serial Presence Detect (SPD) data structure. This allows the BIOS
to read the SPD data and program the chipset to accurately configure memory settings for optimum
performance. If non-SPD memory is installed, the BIOS will attempt to correctly configure the memory
settings, but performance and reliability may be impacted or the DIMMs may not function under the
determined frequency.
The CPU Board has two DDR SO-DIMM sockets with gold-plated contacts
