Multifunction Digital Timer
1/16 DIN Timer with
Easy-to-Use Functions
Nine field-selectable output
modes accommodate a wide
variety of applications
All parameters set by scroll-
through menus accessed from
the front panel
Field-selectable time ranges from
0.001 second to 9999 hours
High-visibility alphanumeric LCD
display has 8 mm high characters
and built-in backlight
Precision control possible to
0.001 second
Four levels of key protection provided
10-year battery back-up
Selectable elapsed time (UP)
and time remaining (DOWN) display
Short body model H5CR-S measures
just 64 mm (2.52 inches) deep
Ordering Information
TIMERS
Add the supply voltage to the part number when you order. For example, H5CR-B-AC100-240.
Timing functions
9 selectable, including ON-delay, repeat cycle, OFF-delay, and one-shot
Contact type
SPDT relay
Product type
Economy
Unit depth
78 mm
(3.07 in)
Panel mounting hardware Not provided
Supply
AC
24 V or 100 to 240 V; 50/60 Hz —
voltage
DC
12 to 24 V
Part
Backlit display
—
number
Unlit display
H5CR-L
Standard
Short body
100 mm
64 mm
(3.94 in)
(2.52 in)
Provided
Provided
—
12 to 24 V
H5CR-B
H5CR-S
—
—
1
Solid-state open collector
Economy
Standard
78 mm
100 mm
(3.07 in)
(3.94 in)
Not provided
Provided
24 V or 100 to 240 V; 50/60 Hz
12 to 24 V
—
—
H5CR-BS
H5CR-LS
—
H5CR
Short body
64 mm
(2.52 in)
Provided
—
12 to 24 V
H5CR-SS
—

Advertisement

Table of Contents
loading

Related Manuals for Omron H5CR

Summary of Contents for Omron H5CR

  • Page 1 Short body model H5CR-S measures just 64 mm (2.52 inches) deep Ordering Information TIMERS Add the supply voltage to the part number when you order. For example, H5CR-B-AC100-240. Timing functions 9 selectable, including ON-delay, repeat cycle, OFF-delay, and one-shot Contact type...

  • Page 2: Specifications

    H5CR H5CR ACCESSORIES Description Part number Soft cover with two mounting clips for front panel protection Y92A-48F1 Shock prevention terminal cover for Standard and Short body timers protects wiring connections Y92A-48T Sockets 8-pin, bottom surface or track mounting, top screw terminals...
  • Page 3 OFF impedance 100 kΩ minimum Response time 1 second Control Type Time limit SPDT relay output or NPN open collector transistor output (H5CR- S) output Instantaneous — Relay Max. load 5 A, 250 VAC resistive load (p.f. = 1) Min. load...

  • Page 4: Timing Charts

    H5CR H5CR Timing Charts The gate input is not included in the H5CR-L . One-shot 1 2 3 Sustained output 1 2 3 One-shot outputs can be set to 0.1 s, 0.5 s, 1 s, 5 s, 10 s, 20 s.
  • Page 5 H5CR H5CR One-shot 1 2 3 Sustained output 1 2 3 One-shot outputs can be set to 0.1 s, 0.5 s, 1 s, 5 s, 10 s, 20 s. 1 2 3 1 2 3 Output mode B: Repeat cycle 1 (Timer resets when power comes ON.) Timing starts when the start signal goes ON.
  • Page 6 H5CR H5CR The gate input is not included in the H5CR-L . One-shot 1 2 3 1 2 3 Sustained output One-shot outputs can be set to 0.1 s, 0.5 s, 1 s, 5 s, 10 s, 20 s. 1 2 3...
  • Page 7 (1.89) 44.8 (1.76) (1.89) ACCESSORIES Y92F-30 Panel Mounting Adaptor The diagram below shows the adapter on an H5CR-L timer. The mounting depths for H5CR-B and H5CR-S are the same as shown in Timer Dimensions . P3G-08 Y92F-30 Panel Rear surface...
  • Page 8 H5CR H5CR P2CF-08 Track Mounting/Front Connecting Sockets Surface Mounting Eight Terminal Arrangement/ (0.18) (0.12) M3.5 x 7.5 sems (0.31) Internal Connections Holes (Top View) Two, 4.5 dia. or two M4 socket mounting holes 35.4 70 max. (1.39) Two 4.5 dia.
  • Page 9 H5CR H5CR Y92A-48F1 Soft plastic cover Y92A-48T Terminal cover Two mounting clips help the soft plastic cover Y92A-48F1 fit The terminal cover protects wiring connections on the snugly over the front of the timer to protect against dirt and Standard and Short Body models.
  • Page 10 H5CR H5CR Connections TERMINAL ARRANGEMENT H5CR-B (Standard) H5CR-L (Economy) H5CR-S (Short body) Contact output Contact output Contact output KEY/P SIGNAL GATE RESET GATE SIGNAL KEY/P RESET SIGNAL RESET TIMED 5 A 250 VAC SOURCE 250 VAC TIMED TIMED SOURCE H5CR-BS...

  • Page 11: Operation

    H5CR H5CR INPUTS The inputs of the H5CR are no-voltage (short circuit or open) inputs. No-contact Input Contact Input No-contact Input (NPN Transistor) (30 V max.) Sensor Sensor Timer Timer Timer 12 VDC Start signal, Start signal, Start signal, reset, etc.
  • Page 12 Outputs made according to designated output mode when corresponding preset is reached. OPERATIONAL OVERVIEW The flowchart below shows operation common to all H5CR models. Refer to the Setting Item Table for details on the operation of specific modes. Press the...
  • Page 13 H5CR H5CR SETTING ITEM TABLE Mode Setting item Description Setting procedure Run mode Set value Compared to the present value. Sequence when changing a digit using the Determines the timing of the control increment keys (1 to 4). output according to the output mode.

  • Page 14: Run Mode

    H5CR H5CR EXAMPLES Run Mode Changing the Set Value To change the set value from 3 hr 5 min to 4 hr 5 min, press the 3 key so that the number 4 appears in the hour's place. • Pressing keys 1 through 4 increments the corresponding column by 1.
  • Page 15 RESET change Memory Set at the factory NOTE: DIMENSIONS ARE SHOWN IN MILLIMETERS. To convert millimeters to inches divide by 25.4. OMRON ELECTRONICS LLC OMRON CANADA, INC. OMRON ON-LINE One East Commerce Drive 885 Milner Avenue Global - http://www.omron.com Schaumburg, IL 60173 Scarborough, Ontario M1B 5V8 USA - http://www.omron.com/oei...
