Battery
Before attaching or removing the battery make sure the radio is turned off by turning the power/volume knob all the way
counter-clockwise.
Installation
To attach the battery, ensure the battery is parallel and in good contact with the aluminum chassis. The
battery bottom is about 1 to 2 centimeters below the bottom of the radio's body.
Align the battery with the guide rails on the radio chassis and slide it upwards until it clicks into place.
The battery latch at the bottom locks the battery in place.
Removal
Ensure the radio is off before removing the battery.
To remove the battery, press the battery release above the battery pack and slide the battery downward.
After sliding the battery down a few centimeters, the battery can be removed from the radio body.
External Headset
Plug the external micro-headset connector into the jack of 'SP & MIC' of the transceiver as shown in
the figure on the right.
