Appendix A
AutoSpid Download
AutoSpid X
CALL <number>
Call Connect B1
Call Connect B2
Call Connect B1/B2
Connected 64K/2X64K/128K
61200176L2-1
The Express 4100/4110 displays current loop status of the ISDN on the
bottom center line of the terminal screen. The following messages are
defined:
The Express 4100/4110 is performing the LUCENT SPID download fea-
ture.
A SPID is being attempted by ExpertISDN. X starts at 0 and counts up
for each SPID format.
The Express 4100/4110 is dialing the number.
Bearer channel B1 is active with a call.
Bearer channel B2 is active with a call.
Bearer channels B1 and B2 are active with a call.
When the Express 4100/4110 is in leased mode, this will appear when the
link's layer 1 is up. The rate is determined by what it is configured for
under Configuration/WAN/ISDN/Leased/Rate.
Express 4100/4110 User Manual
Loop Status Messages
A-1
