Chapter 3. Terminal Menu Operation and Structure

Status/IPX Routes

3-68
P
T
IP Routes/Hops
IP Routes/TTL
Read security: 5
This lists the contents of the Express 4100/4110's IPX router table.
IPX Routes /Network
IPX Routes /Gateway
IPX Routes /Port
local
eth0
wan0
wan1
idle
IPX Routes /Use
IPX Routes/Hops
Express 4100/4110 User Manual
route is private and is not advertised
with RIP
route is to a triggered port (updates
only when table changes)
Number of routers that must go through
to get to destination. Ranges from 0-15
or 16 for infinite (can't get there from
here).
Seconds until address is removed from
table or "zombied." Value of 999
means route is static.
Network destination address
Node or Ethernet address of gateway to
receive this packet
Port gateway is located on:
sent directly to the Express 4100/
4110 router
Express 4100/4110's ethernet port
Express 4100/4110's first PPP bundle
Express 4100/4110's second PPP
bundle
non-connected or "spoofed" route
used for dial-on-demand
Number of times the Express 4100/
4110 has referenced the route
Number of routers that must go through
to get to destination. Ranges from 0-15
or 16 for infinite (can't get there from
here).
