Chapter 3. Terminal Menu Operation and Structure
Menu Path - Gives
current position in
terminal menu structure.
Left Pane - Lists
available menus.
Mode - Describes
current operating
mode.
Loop Status - Dis-
plays current status
of ISDN line.
3-2
Right Pane - Lists available submenus. More sub-
menus available through this pane are indicated
by the [+] and [DATA] symbols.
B-channel status - Displays
current status of each B
channel.

Figure 3-1. Top Level Terminal Menu

Express 4100/4110 User Manual
Navigation Help - Displays list of
characters you can use to navigate
the terminal menus.
61200176L2-1
