C H A P T E R O N E

MFC 7150C Control Panel Overview

28
29
30
Function
Hook
1
Hold
2
Redial / Pause
3
Speed Dial
4
1 Hook
Lets you dial telephone and
fax numbers without lifting
the handset.
2
Hold
Lets you put calls on hold.
3 Redial / Pause
Redials the last number
called. Also inserts a pause
in autodial numbers.
4
Speed Dial
Lets you dial stored phone
numbers by pressing a
two-digit number.
5
Dial Pad
Dials phone and fax numbers,
and can be used as a keyboard
for entering information into the
MFC. # key lets you switch the
dialling type during a telephone
call from "PULSE" to "TONE".
6
Volume High / Low
Adjusts speaker, ring and
handset volume.
7 Shift
To access memory locations
13 through 24 in the One
Touch keys hold down the
Shift key.
8 One Touch Keys
These 12 keys give you instant
access to previously stored
phone numbers.
25
26
27
MFC 715OC
status
status
Set Clear
A B C D E F
High
1 2 3
G H I J K L M N O
Low
5
4 6
PQRS T U V W X YZ
7 8 9
0
5
6
9
Stop
Stops a fax, cancels an
operation, or exits from
function mode.
10 Start
Starts an operation, such as
sending a fax.
11
Enlarge/Reduce
Lets you reduce or enlarge
copies depending on the
ratio you select.
12 Brightness
Lets you adjust the brightness
of the whole image to be lighter
or darker.
13 Paper Type
Use this key to temporarily
change the paper type setting
for Copy and Video Printing
modes.
Copy Quality
14
Use this key to temporarily
change the quality and type
of original for Copy and
Video Printing modes.
15 Mono Copy
Makes a black-and-white or
single-color copy.
16
Color Copy
Makes a full-color copy.
24 23 22
Fine FAX
Photo TAD
S.Fine FAX/TEL
Help/
Tel-index Resolution Mode Broadcast
01 02 03 04
13 14 15 16
Volume
05 06 07 08
17 18 19 20
09 10 11 12
Shift
21 22 23 24
8
7
17 Ink Management
Cleans the ink print heads
and/or resets the ink dot
counter after replacing an
ink cartridge.
18 Priority
Press this key to receive all
faxes in memory without
first printing them.
19 Reset
Clears data from the printer
memory, and then resets and
restores to the factory default
settings.
20
On/OffLine
Use this key to turn the
printer online (ready to
receive PC data) and offline
(not ready to receive PC
data) alternately. When the
printer is online, the LCD
displays ONLINE.
21 Help/Broadcast
Press this key whenever you
want a quick reference Help List
printed. The Help List shows
how to perform functions, how to
register information, and how to
get basic information. Also use
this key whenever you want to
broadcast faxes to many different
locations, maximum of 130
locations at once.
20 19 18
21 17
6 1
IN
FAX PRINTER COPIER SCANNER PC FAX VIDEO CAPTURE
On/Off Line Reset Priority Ink Management
Enlarge/
Brightness Mono Copy Color Copy
Reduce
Paper Type Copy Quality
Stop Start
10
9 12
11 13
22 Mode
Use to select how the MFC
will handle incoming calls.
23 Resolution
Sets the resolution when you
send a fax.
24 Tel-index
Lets you look up numbers
stored in the dialing memory.
25 Ink Empty Indicator
Blinks when ink cartridge is
low and stays lit when ink is
empty.
26 Liquid Crystal Display
LCD displays messages to help
you set and operate your MFC.
27 (Left Arrow)
(Right Arrow)
Moves the LCD cursor
through text and options.
28 Function
Lets you access the function
and programming mode.
29 Set
Stores a function setting in the
MFC.
30 Clear
Deletes entered data or backs
up one step in function
procedure.
15
16
14
