BMW R 1200 R 2008 Rider's Manual page 113

Remove cover 2.
Remove screw 3.
Carefully remove headlight 4
from housing.
Replacing low-beam or
high-beam bulb
If it is not standing firmly,
the motorcycle could topple
in the course of the operations
described below.
Make sure that the motorcycle is
steady on its stand.
Removing headlight from hous-
ing ( 110)
Remove bulb holder of low-
beam bulb 1 by turning it
counterclockwise.
Remove bulb holder of high-
beam bulb 2 by turning it
counterclockwise. If necessary,
pull out bulb socket of parking-
light bulb to simplify removal of
high-beam bulb socket.
Press together clips of bulb
socket 4 on right and left and
remove bulb 3 from bulb sock-
et.
Replace defective bulb.
Bulb for low-beam and
high-beam headlight
H11 / 12 V / 55 W
8
111
