Power supply specifications (per power supply)

Power supply model
XBR-ACPWR-650-F
XBR-ACPWR-650-R
XBR-DCPWR-650-F
XBR-DCPWR-650-R

Power consumption (typical configuration)

All 25 GbE and two 100 GbE ports are linked up, loading with 10 percent traffic rate. Five fan assemblies. Fans at nominal speed.
@100 VAC Input @200 VAC Input
(Input power ±5%) (Input power ±5%)
174 W 171 W
594 BTU/hr 583 BTU/hr
184 W 181 W
628 BTU/hr 618 BTU/hr

Power consumption (maximum configuration)

All 25 GbE and six 100 GbE ports are linked up, loading with 100 percent traffic rate. Two
high speed.
@100 VAC Input @200 VAC Input
(Input power ±5%) (Input power ±5%)
475.9 W 451.9 W
1,624 BTU/hr 1,542 BTU/hr
488.9 W 474.7 W
1,668 BTU/hr 1,620 BTU/hr

Data port specifications (Ethernet)

Port type Number (in module)
100 GbE 6
25 GbE 48
ExtremeSwitching SLX 9140 Hardware Installation Guide
9036857-00 Rev AA
Maximum Input voltage
output power
rating (DC)
650 W 100-240V
650 W 100-240V
650 W -48 - -60V
650 W -48 - -60V
@-48VDC
173 W
590 BTU/hr
183 W
624 BTU/hr
@-48VDC
456.3 W
1,557 BTU/hr
474 W
1,617 BTU/hr
Description
QSFP28 ports, compatible with LR4 or SR4 optical transceivers, or direct attached
copper cable
SFP28 ports, compatible with ER, LR, LRM, SR, ZR, or USR optical transceivers
Input line Maximum
frequency input current
50-60Hz 12 A
50-60Hz 12 A
- 14 A
- 13.3 A
Minimum number Notes
of power supplies
1 x 650 W AC 1 power supply
1 x 650 W DC
1 x 650 W AC 2 power supplies
1 x 650 W DC
Minimum number Notes
of power supplies
1 x 650 W AC 1 power supply
1 x 650 W DC
1 x 650 W AC 2 power supplies
1 x 650 W DC

Power supply specifications (per power supply)

Input line Maximum
protection inrush
current
Fuses 25A
Fuses 25A
Fuses 25A
Fuses 25A
and five fan assemblies. Fans at
power supplies
