5. Connect a power cable from
the power supply to the power
connector at the back of the
HDD. Use the cable with the
white connector labeled P3.
6. Connect one end of the IDE
hard disk ribbon cable to the
IDE interface at the back of
the HDD, matching the red
stripe on the cable with Pin 1
on the IDE interface.
7. Connect the other end of the
IDE ribbon cable to the
primary IDE connector (blue
connector labeled IDE1) on
the motherboard.
ASUS Terminator P4 533 Barebone System
Red Stripe to Pin 1
IDE Ribbon Cable
Primary IDE connector
(IDE1)
Power Cable (P3)
