Figure 4: Installing a micro-SIM Card
3. Gently press the micro-SIM into the slot
until it locks into place. To remove it, press
again and the SIM card will be ejected.
4. Screw the security plate back on using
the two screws removed earlier in order
to protect the SIM card slots.
Note: SIM behavior must be configured from
the web UI before an Internet connection can
be established.
Attach the External Antennas
The DWM-315 requires two external antennas
to function correctly. The included antennas are
interchangeable, but third party antennas may
require connection to specific ports.
Quick Installation Guide
Figure 4: Attaching the Antennas
1. Attach the two LTE antennas to the SMA
connectors on the back of the router
labelled "Main" and "AUX. " Turn clockwise
to fasten the antenna.
2. Place antennas where they will receive
an optimal signal. Arrange them so they
point upward.

Powering the Device

The DWM-315 features flexible power input
ranging from 5 volts / 2 amps to 18 volts /
0.7 amps. A minimum of 10 watts total is
recommended.
