Section 3 - Configuration
This window displays the current information for the Go-RT-N300. It will display the LAN, Internet (WAN), and Wireless information.
If your WAN connection is set up for a Dynamic IP address then a DHCP Release button and a DHCP Renew button will be
displayed. Use DHCP Release to disconnect from your ISP and use DHCP Renew to connect to your ISP.
If your WAN connection is set up for PPPoE, a Connect button and a Disconnect button will be displayed. Use Disconnect to
drop the PPPoE connection and use Connect to establish the PPPoE connection.
System:
Displays the router's time and firmware version.
LAN:
Displays the MAC address and the private (local) IP settings
for the router.
WLAN:
Displays the wireless MAC address and your wireless settings
such as SSID and Channel.
WAN:
Displays the MAC address and the public IP settings for
the router.
