CKM-MR51E
24-10707-58 Rev. E
OPTIONAL BLANK
COVER W/SCREWS
OPTIONAL MAGNETIC
TAMPER SWITCH
OPTIONAL 3-GANG
TO ETHERNET
Figure 4 shows mounting plate dimensions.
2.35 [59.7]
3.30 [83.8]
3.63 [92.1]
Figure 4: CKM-MR51E Mounting Plate Dimensions
JUNCTION BOX
NETWORK
Figure 3: CKM-MR51E Mounting Side View
Ø0.16 [Ø4.0]
3-GANG MGT HOLES
4PL
3.63 [92.1]
3.85 [97.8]
5.50 [139.7]
Hardware Installation Manual
MR51e WITH INCLUDED
MOUNTING PLATE
FIELD WIRING
Ø0.16 [Ø4.0]
MR50 MGT HOLES
4PL
3
